POWERDI is a registered trademark of Diodes Incorporated.
PD3S140Q
Document number: DS36995 Rev. 1 - 2
2 of 5
March 2014
© Diodes Incorporated
PD3S140Q
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic Symbol
Value
Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
V
RRM
V
RWM
V
R
40 V
Average Forward Current (See also figure 4)
I
F(AV)
1.0 A
Non-Repetitive Peak Forward Surge Current 8.3ms
single half sine-wave superimposed on rated load
I
FSM
22 A
Thermal Characteristics
Characteristic Symbol
Typ
Max
Unit
Thermal Resistance Junction to Soldering Point
R
θJS
⎯
15 °C/W
Thermal Resistance Junction to Ambient Air (Note 6)
R
θJA
175
⎯
°C/W
Thermal Resistance Junction to Ambient Air (Note 7)
R
θJA
130
⎯
°C/W
Operating and Storage Temperature Range
T
J
, T
STG
-55 to +150
°C
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Min
Typ
Max
Unit
Test
Condition
Reverse Breakdown Voltage (Note 8)
V
(BR)R
40
⎯
⎯
V
I
R
= 100µA
Forward Voltage
V
F
⎯
0.37 0.42
V
I
F
= 0.1A
⎯
0.44 0.50
I
F
= 0.5A
⎯
0.46 0.52
I
F
= 0.7A
⎯
0.49 0.55
I
F
= 1.0A
Leakage Current (Note 8)
I
R
⎯
0.3 4
µA
V
R
= 5V, T
A
= +25
°C
⎯
2 50
V
R
= 40V, T
A
= +25
°C
Total Capacitance (See also figure 3)
C
T
⎯
32
⎯
pF
V
R
= 10V, f = 1.0MHz
Notes:
6. FR-4 PCB, 2 oz. Copper, minimum recommended pad lay
A
= +25°C.
7. Polymide PCB, 2 oz. Copper, minimum recommended pad layout pe
A
= +25°C.
8. Short duration pulse test used to minimize self-heating effect.
