Diodes DZQA6V8AXV5 - Manual (Page 3)

DZQA6V8AXV5
Document number: DS31271 Rev. 6 - 2
3 of 4
www.diodes.com
February 2011
© Diodes Incorporated
DZQA6V8AXV5
0.0001
0.001
0.01
0.1
1
0.5 0.7 0.9 1.1 1.3 1.5
V , INSTANTANEOUS FORWARD VOLTAGE (V)
Fig. 3 Typical Forward Characteristics
F
I,
I
N
S
T
A
N
T
A
N
E
O
U
S F
O
R
WA
R
D
C
U
R
R
E
N
T
(mA
)
F 0
2
4
6
8
10
12
14
0 1.0 2.0 3.0 4.0 5.0
f = 1.0MHz
V , REVERSE VOLTAGE (V)
Fig. Typical Total Capacitance vs.
Reverse Voltage (Per Element)
R
4
C,
T
O
T
A
L
CA
P
A
CIT
A
NCE
(
p
F
)
T
Package Outline Dimensions
Suggested Pad Layout
SOT553
Dim Min Max Typ
A 0.55 0.60 0.60
c 0.10 0.18 0.15
D 1.50 1.70 1.60
E 1.55 1.70 1.60
E1 1.10 1.25 1.20
L 0.10 0.30 0.20
b 0.15 0.30 0.20
e 0.50 Typ
e1 1.00 Typ
a 6° 8° 7°
All Dimensions in mm
Dimensions Value (in mm)
Z 2.2
G 1.2
X 0.375
Y 0.5
C1 1.7
C2 0.5
c
L
A
D
E
E1
b (5 places)
e1
e
a
X
Z
Y
C1
C2 C2
G
