DESD5V2S2UT
Document number: DS31791 Rev. 3 - 2
2 of 4
September 2009
© Diodes Incorporated
DESD5V2S2UT
NEW PROD
UC
T
I
, P
EAK
PUL
S
E C
URRE
NT
(
%
I
)
Pp
p
t, TIME (ms)
Fig. 1 Pulse Waveform
I
, P
EAK
PUL
S
E CURRE
NT
(
%
I
)
pp
pp
t, TIME ( s)
μ
Fig. 2 Pulse Waveform
1
10
100
1,000
10,000
1
10
100
1,000
10,000
t , PULSE DURATION (µs)
d
Fig. 3 Max. Peak Pulse Power vs. Pulse Duration
P
,
P
E
AK
P
U
LS
E
P
O
WE
R
(W
)
PK
0
20
40
60
80
100
120
140
160
180
200
0
1
2
3
4
5
6
Fig. 4 Typical Total Capacitance vs. Reverse Voltage
V , REVERSE VOLTAGE (V)
R
C
, T
O
T
A
L
CAP
A
CI
T
A
NCE
(p
F
)
T
f = 1MHz
Ordering Information
(Note 8)
Part Number
Case
Packaging
DESD5V2S2UT-7
SOT-23
3000/Tape & Reel
Notes:
8. For packaging details, go to our website at
Marking Information
Date Code Key
Year
2009
2010
2011
2012
2013 2014 2015
Code
W X Y Z A B C
Month
Jan
Feb
Mar
Apr
May
Jun
Jul
Aug
Sep
Oct
Nov
Dec
Code 1 2 3 4 5 6 7 8 9 O N D
ED6 = Product Type Marking Code
YM = Date Code Marking
Y = Year (ex: W = 2009)
M = Month (ex: 9 = September)
ED6
YM
