DS21503 Rev. 11 - 2
2 of 4
1.5KE6V8(C)A - 1.5KE400(C)A
www.diodes.com
Type
Number
(Note 1)
Type
Number
(Note 1)
Reverse
Standoff
Voltage
Breakdown Voltage
V
BR
@ I
T
Test
Current
Max.
Reverse
Leakage
(Note 2)
@ V
R
Max.
Clamping
Voltage
@ I
pp
Max.
Peak
Pulse
Current
Max.
Voltage
Temp.
Variation
of V
BR
(UNI)
(BI)
V
RWM
(V)
Min (V)
Max (V)
I
t
(mA)
I
R
(m
A)
V
C
(V)
I
PP
(A)
%/°C
1.5KE6V8A 1.5KE6V8CA
5.80
6.45
7.14
10
1000
10.5
143.0
0.057
1.5KE7V5A 1.5KE7V5CA
6.40
7.13
7.88
10
500
11.3
132.0
0.061
1.5KE8V2A 1.5KE8V2CA
7.02
7.79
8.61
10
200
12.1
124.0
0.065
1.5KE9V1A 1.5KE9V1CA
7.78
8.65
9.55
1.0
50
13.4
112.0
0.068
1.5KE10A
1.5KE10CA
8.55
9.50
10.50
1.0
10
14.5
103.0
0.073
1.5KE11A
1.5KE11CA
9.40
10.50
11.60
1.0
5.0
15.6
96.0
0.075
1.5KE12A
1.5KE12CA
10.20
11.40
12.60
1.0
5.0
16.7
90.0
0.078
1.5KE13A
1.5KE13CA
11.10
12.40
13.70
1.0
5.0
18.2
82.0
0.081
1.5KE15A
1.5KE15CA
12.80
14.30
15.80
1.0
5.0
21.2
71.0
0.084
1.5KE16A
1.5KE16CA
13.60
15.20
16.80
1.0
5.0
22.5
67.0
0.086
1.5KE18A
1.5KE18CA
15.30
17.10
18.90
1.0
5.0
25.2
59.5
0.088
1.5KE20A
1.5KE20CA
17.10
19.00
21.00
1.0
5.0
27.7
54.0
0.090
1.5KE22A
1.5KE22CA
18.80
20.90
23.10
1.0
5.0
30.6
49.0
0.092
1.5KE24A
1.5KE24CA
20.50
22.80
25.20
1.0
5.0
33.2
45.0
0.094
1.5KE27A
1.5KE27CA
23.10
25.70
28.40
1.0
5.0
37.5
40.0
0.096
1.5KE30A
1.5KE30CA
25.60
28.50
31.50
1.0
5.0
41.4
36.0
0.097
1.5KE33A
1.5KE33CA
28.20
31.40
34.70
1.0
5.0
45.7
33.0
0.098
1.5KE36A
1.5KE36CA
30.80
34.20
37.80
1.0
5.0
49.9
30.0
0.099
1.5KE39A
1.5KE39CA
33.30
37.10
41.00
1.0
5.0
53.9
28.0
0.100
1.5KE43A
1.5KE43CA
36.80
40.90
45.20
1.0
5.0
59.3
25.3
0.101
1.5KE47A
1.5KE47CA
40.20
44.70
49.40
1.0
5.0
64.8
23.2
0.101
1.5KE51A
1.5KE51CA
43.60
48.50
53.60
1.0
5.0
70.1
21.4
0.102
1.5KE56A
1.5KE56CA
47.80
53.20
58.80
1.0
5.0
77.0
19.5
0.103
1.5KE62A
1.5KE62CA
53.00
58.90
65.10
1.0
5.0
85.0
17.7
0.104
1.5KE68A
1.5KE68CA
58.10
64.60
71.40
1.0
5.0
92.0
16.3
0.104
1.5KE75A
1.5KE75CA
64.10
71.30
78.80
1.0
5.0
103.0
14.6
0.105
1.5KE82A
1.5KE82CA
70.10
77.90
86.10
1.0
5.0
113.0
13.3
0.105
1.5KE91A
1.5KE91CA
77.80
86.50
95.50
1.0
5.0
125.0
12.0
0.106
1.5KE100A
1.5KE100CA
85.50
95.00
105.00
1.0
5.0
137.0
11.0
0.106
1.5KE110A
1.5KE110CA
94.00
105.00
116.00
1.0
5.0
152.0
9.9
0.107
1.5KE120A
1.5KE120CA
102.00
114.00
126.00
1.0
5.0
165.0
9.1
0.107
1.5KE130A
1.5KE130CA
111.00
124.00
137.00
1.0
5.0
179.0
8.4
0.107
1.5KE150A
1.5KE150CA
128.00
143.00
158.00
1.0
5.0
207.0
7.2
0.108
1.5KE160A
1.5KE160CA
136.00
152.00
168.00
1.0
5.0
219.0
6.8
0.108
1.5KE170A
1.5KE170CA
145.00
162.00
179.00
1.0
5.0
234.0
6.4
0.108
1.5KE180A
1.5KE180CA
154.00
171.00
189.00
1.0
5.0
246.0
6.1
0.108
1.5KE200A
1.5KE200CA
171.00
190.00
210.00
1.0
5.0
274.0
5.5
0.108
1.5KE220A
1.5KE220CA
185.00
209.00
231.00
1.0
5.0
328.0
4.6
0.108
1.5KE250A
1.5KE250CA
214.00
237.00
263.00
1.0
5.0
344.0
5.0
0.110
1.5KE300A
1.5KE300CA
256.00
285.00
315.00
1.0
5.0
414.0
5.0
0.110
1.5KE350A
1.5KE350CA
300.00
332.00
368.00
1.0
5.0
482.0
4.0
0.110
1.5KE400A
1.5KE400CA
342.00
380.00
420.00
1.0
5.0
548.0
4.0
0.110
Notes: 1. Suffix ‘C’ denotes bidirectional device.
2. For bidirectional devices having V
R
of 10 volts and under, the I
R
limit is doubled.
