Thermal Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Value
Units
Total Power Dissipation (Note 5)
P
D
1.5 W
Thermal Resistance, Junction to Ambient (Note 5)
Steady State
R
θJA
85
°C/W
t<10s 53
Thermal Resistance, Junction to Case
R
θJC
15
Operating and Storage Temperature Range
T
J,
T
STG
-55 to +150
°C
Maximum Ratings
N-CHANNEL
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Value
Units
Drain-Source Voltage
V
DSS
40 V
Gate-Source Voltage
V
GSS
±20 V
Continuous Drain Current (Note 5) V
GS
= 10V
Steady
State
T
A
= +25°C
T
A
= +70°C
I
D
4.5
3.5
A
t<10s
T
A
= +25°C
T
A
= +70°C
I
D
5.8
4.5
A
Continuous Drain Current (Note 5) V
GS
= 4.5V
Steady
State
T
A
= +25°C
T
A
= +70°C
I
D
4
3.1
A
t<10s
T
A
= +25°C
T
A
= +70°C
I
D
5.1
4
A
Maximum Continuous Body Diode Forward Current (Note 5)
I
S
1.5
A
Pulsed Drain Current (10µs pulse, duty cycle = 1%)
I
DM
25
A
Maximum Ratings
P-CHANNEL
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Value
Units
Drain-Source Voltage
V
DSS
-40 V
Gate-Source Voltage
V
GSS
±20 V
Continuous Drain Current (Note 5) V
GS
= -10V
Steady
State
T
A
= +25°C
T
A
= +70°C
I
D
-3.7
-2.9
A
t<10s
T
A
= +25°C
T
A
= +70°C
I
D
-4.8
-3.8
A
Continuous Drain Current (Note 5) V
GS
= -4.5V
Steady
State
T
A
= +25°C
T
A
= +70°C
I
D
-2.9
-2.3
A
t<10s
T
A
= +25°C
T
A
= +70°C
I
D
-3.9
-3.0
A
Maximum Continuous Body Diode Forward Current (Note 5)
I
S
-1.5
A
Pulsed Drain Current (10µs pulse, duty cycle = 1%)
I
DM
-15
A
Note:
5. Device mounted on FR-4 substrate PC board, 2oz copper, with 1inch square copper plate.
