40V COMPLEMENTARY ENHANCEMENT MODE MOSFET H-BRIDGE
Product Summary
Device
V
(BR)DSS
R
DS(ON)
max
I
D
max
T
A
= +25°C
N-Channel 40V
45mΩ @ V
GS
= 10V
4.5A
58mΩ @ V
GS
= 4.5V
4A
P-Channel -40V
65mΩ @ V
GS
= -10V
-3.7A
100mΩ @ V
GS
= -4.5V
-2.9A
Description
This new generation complementary MOSFET H-Bridge features low
on-resistance achievable with low gate drive.
Applications
•
DC Motor Control
• DC-AC
Inverters
Features
•
2 x N + 2 x P channels in a SOIC package
• Low
On-Resistance
•
Low Input Capacitance
•
Fast Switching Speed
•
Totally Lead-Free & Fully RoHS compliant (Notes 1 & 2)
•
Halogen and Antimony Free. “Green” Device (Note 3)
•
Qualified to AEC-Q101 Standards for High Reliability
Mechanical Data
• Case:
SO-8
•
Case Material: Molded Plastic, "Green" Molding Compound.
UL Flammability Classification Rating 94V-0
•
Moisture Sensitivity: Level 1 per J-STD-020
• Terminal
Connections
Indicator: See diagram
• Terminals:
Finish
⎯ Matte Tin annealed over Copper leadframe.
Solderable per MIL-STD-202, Method 208
•
Weight: 0.074 grams (approximate)
Ordering Information
(Note 4)
Part Number
Compliance Case
Packaging
DMHC4035LSD-13
Standard
SO-8
2500/Tape & Reel
Notes:
1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.
2. S more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green"
and Lead-free.
3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and
<1000ppm antimony compounds.
4. For packaging details, go to our website at
Marking Information
Top View
Internal Schematic
Top View
Pin Configuration
SO-8
H-Bridge
P1
G
P1
S/
P2
S
N2
D
/P
2D
P2
G
N
2G
N1
S
/N2
S
N1
D/
P
1D
N1
G
1
4
8
5
C4035LS
YY
WW
= Manufacturer’s Marking
C4035LS = Product Type Marking Code
YYWW = Date Code Marking
YY = Year (ex: 13 = 2013)
WW = Week (01 - 53)
