DMP32D4SFB
Document number: DS36161 Rev. 2 - 2
1 of 6
March 2013
© Diodes Incorporated
DMP32D4SFB
ADVAN
CE I
N
F
O
RM
ATI
O
N
NEW PROD
UC
T
30V P-CHANNEL ENHANCEMENT MODE MOSFET
Product Summary
V
(BR)DSS
R
DS(on)
Max
I
D
Max
@ T
A
= +25
C
-30V
2.4
@ V
GS
= -10V
-400mA
4
@ V
GS
= -4.5V
-300mA
16
@ V
GS
= -2.5V
-50mA
Description
This MOSFET has been designed to minimize the on-state resistance
(R
DS(on)
) and yet maintain superior switching performance, making it
ideal for high efficiency power management applications.
Applications
Load
Switch
Portable
Applications
Power Management Functions
Features
Low
On-Resistance
Ultra-Small Surfaced Mount Package
ESD Protected Gate
Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)
Halogen and Antimony Free. “Green” Device (Note 3)
Qualified to AEC-Q101 Standards for High Reliability
Mechanical Data
Case:
X1-DFN1006-3
Case Material: Molded Plastic, “Green” Molding Compound.
UL Flammability Classification Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020
Terminal Connections: See Diagram
Terminals: Finish – NiPdAu over Copper leadframe. Solderable
per MIL-STD-202, Method 208
Weight: 0.001 grams (approximate)
Ordering Information
(Note 4)
Product
Marking
Reel size (inches)
Quantity per reel
DMP32D4SFB-7B XP 7
10,000
Notes:
1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.
2. S
and Lead-free.
3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and
<1000ppm antimony compounds.
4. For packaging details, go to our website at http”
Marking Information
ESD PROTECTED
Bottom View
Top View
D
S
G
X1-DFN1006-3
XP = Product Type Marking Code
Top View
Bar Denotes Gate and Source Side
Equivalent Circuit
Source
Gate
Protection
Diode
Gate
Drain
XP
e4
