DMP3098LSD
NEW PROD
UC
T
D1
S1
G1
D2
S2
G2
DUAL P-CHANNEL ENHANCEMENT MODE MOSFET
Product Summary
V
(BR)DSS
R
DS(on) max
I
D
T
A
= +25°C
-30V
65m
Ω @ V
GS
= -10V
-4.4A
115m
Ω @ V
GS
= -4.5V
-3.2A
Description
This new generation MOSFET has been designed to minimize the
on-state resistance (R
DS(ON)
) and yet maintain superior switching
performance, making it ideal for high efficiency power management
applications.
Applications
•
Power Management Functions
• Analog
Switch
• Load
Switch
• Boost
Switch
Features
•
Dual P-Channel MOSFET
• Low
On-Resistance
•
Low Gate Threshold Voltage
•
Low Input Capacitance
•
Fast Switching Speed
•
Low Input/Output Leakage
•
Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)
•
Halogen and Antimony Free. “Green” Device (Note 3)
•
Qualified to AEC-Q101 Standards for High Reliability
Mechanical Data
• Case:
SO-8
•
Case Material: Molded Plastic, “Green” Molding Compound.
UL Flammability Classification Rating 94V-0
•
Moisture Sensitivity: Level 1 per J-STD-020
• Terminal
Connections
Indicator: See Diagram
•
Terminals: Finish - Matte Tin annealed over Copper lead
frame. Solderable per MIL-STD-202, Method 208
•
Weight: 0.072g (approximate)
Ordering Information
(Note 4)
Part Number
Case
Packaging
DMP3098LSD-13
SO-8
2,500/Tape & Reel
Notes:
1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.
2. S
and Lead-free.
3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and
<1000ppm antimony compounds.
4. For packaging details, go to our website at
Marking Information
SO-8
TOP VIEW
Internal Schematic
TOP VIEW
S1
D2
S2
D1
G2
G1
D1
D2
1
4
8
5
P3098LD
YY WW
= Manufacturer’s Marking
P3098LD = Product Type Marking Code
YYWW = Date Code Marking
YY or YY = Year (ex: 14 = 2014)
WW = Week (01 - 53)
YY = Date Code Marking for SAT (Shanghai Assembly/ Test site)
YY = Date Code Marking for CAT (Chengdu Assembly/ Test site)
1
4
8
5
P3098LD
YY
WW
Chengdu A/T Site
Shanghai A/T Site
P-Channel MOSFET
P-Channel MOSFET
e3
