Diodes DMP3065LVT User Manual
Product summary, Description and applications, Features and benefits

DMP3065LVT
Document number: DS36697 Rev. 2 - 2
1 of 6
February 2014
© Diodes Incorporated
DMP3065LVT
ADVAN
CE I
N
F
O
RM
ATI
O
N
P-CHANNEL ENHANCEMENT MODE MOSFET
Product Summary
V
(BR)DSS
R
DS(ON)
max
I
D
max
T
A
= +25°C
-30V
42mΩ @ V
GS
= -10V
-4.9A
65mΩ @ V
GS
= -4.5V
-3.7A
Description and Applications
This MOSFET has been designed to minimize the on-state resistance
(R
DS(ON)
) and yet maintain superior switching performance, making it
ideal for high efficiency power management applications.
• Backlighting
•
Power Management Functions
• DC-DC
Converters
Features and Benefits
• Low
On-Resistance
•
Low Input Capacitance
•
Fast Switching Speed
• ESD
Protected
Gate
•
Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)
•
Halogen and Antimony Free. “Green” Device (Note 3)
•
Qualified to AEC-Q101 Standards for High Reliability
Mechanical Data
• Case:
TSOT26
•
Case Material: Molded Plastic, “Green” Molding Compound. UL
Flammability Classification Rating 94V-0
•
Moisture Sensitivity: Level 1 per J-STD-020
•
Terminal Connections: See Diagram
• Terminals:
Finish
⎯ Matte Tin annealed over Copper leadframe.
Solderable per MIL-STD-202, Method 208
•
Weight: 0.015 grams (approximate)
Ordering Information
(Note 4)
Part Number
Case
Packaging
DMP3065LVT-7
TSOT26
3,000/Tape & Reel
DMP3065LVT-13
TSOT26
10,000/Tape & Reel
Notes:
1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.
2. S
and Lead-free.
3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and
<1000ppm antimony compounds.
4. For packaging details, go to our website at
Marking Information
Date Code Key
Year
2011
2012
2013
2014
2015
2016
2017
Code Y Z A B C D E
Month
Jan
Feb
Mar
Apr
May
Jun
Jul
Aug
Sep
Oct
Nov
Dec
Code 1 2 3 4 5 6 7 8 9 O N D
Top View
Top View
Internal Schematic
ESD PROTECTED
TSOT26
1
2
3
6
5
4
D
D
D
D
G
S
Equivalent Circuit
65P = Product Type Marking Code
YM = Date Code Marking for SAT (Shanghai Assembly/ Test site)
Y̅M = Date Code Marking for CAT (Chengdu Assembly/ Test site)
Y or Y̅ = Year (ex: A = 2013)
M = Month (ex: 9 = September)
Shanghai A/T Site
Chengdu A/T Site
e3
