Diodes DMP3017SFG - Manual

POWERDI is a registered trademark of Diodes Incorporated
DMP3017SFG
Document number: DS36479 Rev. 3 - 2
1 of 7
www.diodes.com
December 2013
© Diodes Incorporated
DMP3017SFG
ADVAN
CE I
N
F
O
RM
ATI
O
N
30V P-CHANNEL ENHANCEMENT MODE MOSFET
POWERDI ®
Product Summary
V
(BR)DSS
R
DS(ON)
max
I
D
max
T
A
= +25°C
-30V
10mΩ @ V
GS
= -10V -11.5A
18mΩ @ V
GS
= -4.5V -8.7A
Description
This MOSFET has been designed to minimize the on-state resistance
(R
DS(ON)
) and yet maintain superior switching performance, making it
ideal for high efficiency power management applications.
Applications
 Backlighting

Power Management Functions
 DC-DC Converters
Features and Benefits
 Low R
DS(ON)
– ensures on state losses are minimized
 Small form factor thermally efficient package enables higher
density end products
 Occupies just 33% of the board area occupied by SO-8 enabling
smaller end product
 ESD Protected Gate
 Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)
 Halogen and Antimony Free. “Green” Device (Note 3)
 Qualified to AEC-Q101 Standards for High Reliability
Mechanical Data
 Case: POWERDI3333-8
 Case Material: Molded Plastic, "Green" Molding Compound.
UL Flammability Classification Rating 94V-0
 Moisture Sensitivity: Level 1 per J-STD-020
 Terminal Connections Indicator: See diagram
Terminals: Finish – Matte Tin annealed over Copper leadframe.
Solderable per MIL-STD-202, Method 208
 Weight: 0.072 grams (approximate)
Ordering Information
(Note 4)
Part Number Case Packaging
DMP3017SFG-7 POWERDI3333-8 2,000/Tape & Reel
DMP3017SFG-13 POWERDI3333-8 3,000/Tape & Reel
Notes: 1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.
2. See http://www.diodes.com/quality/lead_free.html for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green"
and Lead-free.
3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and
<1000ppm antimony compounds.
4. For packaging details, go to our website at http://www.diodes.com/products/packages.html.
Marking Information
Bottom View
S
S
S
G
D
D
D
D
Pin 1
Top View
P17= Product Type Marking Code
YYWW = Date Code Marking
YY = Last digit of year (ex: 13 = 2013)
WW = Week code (01 ~ 53)
P17
Y
YWW
ESD PROTECTED
Equivalent Circuit
D
S
G
Gate Protection
Diode
