DMP2070UCB6
Document number: DS35553 Rev. 2 - 2
1 of 6
October 2011
© Diodes Incorporated
DMP2070UCB6
NEW PROD
UC
T
P-CHANNEL ENHANCEMENT MODE MOSFET
Product Summary
V
(BR)DSS
R
DS(ON)
I
D
T
A
= 25°C
-20V
70m
Ω @ V
GS
= -4.5V
3.5 A
90m
Ω @ V
GS
= -2.5V
3.0 A
Description and Applications
This new generation MOSFET has been designed to minimize the on-
state resistance (R
DS(on)
) and yet maintain superior switching
performance, making it ideal for high efficiency power management
applications.
• Battery Management
• Load Switch
• Battery Protection
Features and Benefits
• Low
Q
g
& Q
gd
• Small
Footprint
•
Low Profile 0.62mm height
•
Lead Free By Design/RoHS Compliant (Note 1)
•
"Green" Device Halogen and Antimony Free (Note 2)
•
Qualified to AEC-Q101 Standards for High Reliability
Mechanical Data
• Case:
U-WLB1510-6
•
Terminal Connections: See Diagram Below
•
Weight: 0.0018 grams (approximate)
Ordering Information
(Note 3)
Part Number
Case
Packaging
DMP2070UCB6-7
U-WLB1510-6
3000/Tape & Reel
Notes:
1. No purposefully added lead.
2. Diodes Inc.’s “Green” policy can be found on our w
Marking Information
Date Code Key
Year
2011
2012
2013
2014
2015
2016
2017
Code Y
Z
A
B
C D
E
Month
Jan
Feb
Mar
Apr
May
Jun
Jul
Aug
Sep
Oct
Nov
Dec
Code 1 2 3 4 5 6 7 8 9 O N D
U-WLB1510-6
2W = Product Type Marking Code
YM = Date Code Marking
Y = Year (ex: Y = 2011)
M = Month (ex: 9 = September)
Top View
2W
YM
D
D
S
S
S
G
