Diodes DMP2038USS User Manual
Dmp2038uss new prod uc t d, Product summary, Description and applications

DMP2038USS
Document number: DS36919 Rev. 2 - 2
1 of 6
April 2014
© Diodes Incorporated
DMP2038USS
NEW PROD
UC
T
D
Top View
SO-8
D
S
S
S
G
D
D
D
Top View
Pin-Out
Equivalent Circuit
S
G
20V P-CHANNEL ENHANCEMENT MODE MOSFET
Product Summary
V
(BR)DSS
R
DS(ON)
max
I
D
max
T
A
= +25°C
-20V
38mΩ @ V
GS
= -4.5V
-6.5A
56mΩ @ V
GS
= -2.5V
-5.0A
Description and Applications
This MOSFET has been designed to minimize the on-state
resistance (R
DS(ON)
) and yet maintain superior switching
performance, making it ideal for high efficiency power management
applications.
• Backlighting
•
Power Management Functions
• DC-DC
Converters
Features and Benefits
• Low
On-Resistance
•
Low Gate Threshold Voltage
•
Low Input Capacitance
•
Fast Switching Speed
•
Low Input/Output Leakage
•
Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)
•
Halogen and Antimony Free. “Green” Device (Note 3)
•
Qualified to AEC-Q101 standards for High Reliability
Mechanical Data
• Case:
SO-8
•
Case Material: Molded Plastic, “Green” Molding Compound.
UL Flammability Classification Rating 94V-0
•
Moisture Sensitivity: Level 1 per J-STD-020
•
Terminals Connections: See Diagram
•
Terminals: Finish - Matte Tin annealed over Copper lead
frame. Solderable per MIL-STD-202, Method 208
•
Weight: 0.072g (approximate)
Ordering Information
(Note 4)
Part Number
Case
Packaging
DMP2038USS-13
SO-8
2500/Tape & Reel
Notes:
1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.
2. S
and Lead-free.
3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and
<1000ppm antimony compounds.
4. For packaging details, go to our website at
Marking Information
Chengdu A/T Site
Shanghai A/T Site
= Manufacturer’s Marking
P2038US = Product Type Marking Code
YYWW = Date Code Marking
YY or YY = Year (ex: 13 = 2013)
WW = Week (01 - 53)
YY = Date Code Marking for SAT (Shanghai Assembly/ Test site)
YY = Date Code Marking for CAT (Chengdu Assembly/ Test site)
e3
