DMGD7N45SSD

Document number: DS36011 Rev. 7 - 2

2 of 7

www.diodes.com

February 2014

© Diodes Incorporated

DMGD7N45SSD

NEW PROD

UC

T



Maximum Ratings

(@T

A

= +25°C, unless otherwise specified.)

Characteristic Symbol

Value

Units

Drain-Source Voltage

V

DSS

450 V

Gate-Source Voltage

V

GSS

±30 V

Continuous Drain Current (Note 5) V

GS

= 10V

Steady State

I

D

0.5

A

t < 10s

0.62

t < 1s

0.85

A

Pulsed Drain Current (10µs pulse, duty cycle = 1%)

I

DM

2.2 A

Maximum Body Diode Forward Current (Note 5)

I

S

1.7 A

Avalanche Current (Note 6)

L = 60mH

I

AS

1.4

A

L = 10mH (Note 8)

2.2

Avalanche Energy (Note 6)

L = 60mH

E

AS

56

mJ

L = 10mH (Note 8)

25


Thermal Characteristics

Characteristic Symbol

Value

Units

Total Power Dissipation (Note 5)

P

D

1.64 W

Thermal Resistance, Junction to Ambient (Note 5)

Steady state

R

ΘJA

78 °C/W

t<10s 20.2

°C/W

Thermal Resistance, Junction to Case (Note 5)

R

ΘJC

13.3 °C/W

Operating and Storage Temperature Range

T

J,

T

STG

-55 to +150

°C


Electrical Characteristics

(@T

A

= +25°C, unless otherwise specified.)

Characteristic Symbol

Min

Typ

Max

Unit

Test

Condition

OFF CHARACTERISTICS (Note 7)
Drain-Source Breakdown Voltage

BV

DSS

450

V

V

GS

= 0V, I

D

= 10mA

Zero Gate Voltage Drain Current

I

DSS

1 µA

V

DS

= 450V, V

GS

= 0V

Gate-Source Leakage

I

GSS

±100

nA

V

GS

=

±30V, V

DS

= 0V

ON CHARACTERISTICS (Note 7)
Gate Threshold Voltage

V

GS(th)

3.5

4.5 V

V

DS

=10V I

D

= 1mA

Static Drain-Source On-Resistance

R

DS (ON)

3 4 Ω

V

GS

= 10V, I

D

= 0.4A

Forward Transfer Admittance

|Y

fs

|

0.55 1.1

S

V

DS

= 10V, I

D

=0.4A

Diode Forward Voltage

V

SD

0.7 1.2 V

V

GS

= 0V, I

S

= 0.7A

DYNAMIC CHARACTERISTICS (Note 8)
Input Capacitance

C

iss

256

pF

V

DS

= 25V, V

GS

= 0V

f = 1MHz

Output Capacitance

C

oss

22.5

Reverse Transfer Capacitance

C

rss

0.83

Gate Resistance

R

G

2.3

V

DS

= 0V, V

GS

= 0V, f = 1MHz

Total Gate Charge (V

GS

= 10V)

Q

g

6.9

nC

V

DS

= 360V,I

D

= 0.7A, V

GS

= 10V

Gate-Source Charge

Q

gs

1.4

Gate-Drain Charge

Q

gd

3.4

Turn-On Delay Time

t

D(on)

7

nS

V

GS

= 10V, R

L

= 562Ω

, R

G

= 10Ω,

I

D

= 0.4A

Turn-On Rise Time

t

r

6.4

Turn-Off Delay Time

t

D(off)

18.9

Turn-Off Fall Time

t

f

56.6

Body Diode Reverse Recovery Time

t

rr

103

nS

I

F

= 1A, dI/dt = 100A/μs

Body Diode Reverse Recovery Charge

Q

rr

314

nC

Notes:

5. Device mounted on FR-4 substrate PC board, 2oz copper, with 1inch square copper plate.
6. I

AR

and E

AR

rating are based on low frequency and duty cycles to keep T

J

= +25°C.

7. Short duration pulse test used to minimize self-heating effect.
8. Guaranteed by design. Not subject to product testing.
