DMN6040SFDE
D
atasheet number: DS35792 Rev. 8 - 2
1 of 6
August 2012
© Diodes Incorporated
DMN6040SFDE
ADVAN
CE I
N
F
O
RM
ATI
O
N
60V N-CHANNEL ENHANCEMENT MODE MOSFET
Product Summary
V
(BR)DSS
R
DS(ON) max
Package
I
D max
T
A
= +25°C
60V
38m
Ω @ V
GS
= 10V
U-DFN2020-6
Type E
6.5A
47m
Ω @ V
GS
= 4.5V
5.2A
Description
This new generation MOSFET has been designed to minimize the on-
state resistance (R
DS(on)
) and yet maintain superior switching
performance, making it ideal for high efficiency power management
applications.
Applications
•
General Purpose Interfacing Switch
•
Power Management Functions
Features and Benefits
•
100% Unclamped Inductive Switch (UIS) test in production
•
0.6mm profile – ideal for low profile applications
•
PCB footprint of 4mm
2
•
Low On-Resistance
•
Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)
•
Halogen and Antimony Free. "Green" Device (Note 3)
•
Qualified to AEC-Q101 Standards for High Reliability
Mechanical Data
•
Case: U-DFN2020-6 Type E
•
Case Material: Molded Plastic, “Green” Molding Compound.
UL Flammability Classification Rating 94V-0
•
Moisture Sensitivity: Level 1 per J-STD-020
•
Terminals: Finish – NiPdAu over Copper leadframe. Solderable
per MIL-STD-202, Method 208
•
Weight: 0.0065 grams (approximate)
Ordering Information
(Note 4)
Part Number
Marking
Reel size (inches)
Quantity per reel
DMN6040SFDE-7 N8
7
3,000
DMN6040SFDE-13 N8
13
10,000
Notes:
1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.
2. S
3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and
<1000ppm antimony compounds.
4. For packaging details, go to our website at
Marking Information
Date Code Key
Year
2011
2012
2013
2014
2015
2016
2017
Code Y
Z
A
B
C D
E
Month
Jan
Feb
Mar
Apr
May
Jun
Jul
Aug
Sep
Oct
Nov
Dec
Code 1 2 3 4 5 6 7 8 9 O N D
U-DFN2020-6 Type E
Bottom View
Pin Out
N8 = Product Type Marking Code
YM = Date Code Marking
Y = Year (ex: Y = 2011)
M = Month (ex: 9 = September)
Equivalent Circuit
Source
Gate
Drain
Bottom View
Pin1
e4
