DMG1026UV
Document number: DS35068 Rev. 6 - 2
5 of 6
www.diodes.com
February 2014
© Diodes Incorporated
DMG1026UV
0.001 0.01 0.1 1 10 100 1,000
Figure 13 Transient Thermal Response
t , PULSE DURATION TIME (s)
1
0.000001 0.0001 0.00001
0.001
0.01
0.1
1
r(t),
T
R
ANSI
EN
T
T
H
E
R
MA
L
R
ESI
S
TAN
C
E
T - T = P * R (t)
Duty Cycle, D = t /t
J A JA
1 2
θ
R (t) = r(t) *
θJA
R
R = 220°C/W
θ
θ
JA
JA
P(pk)
t
1
t
2
D = 0.7
D = 0.3
D = 0.1
D = 0.05
D = 0.02
D = 0.01
D = 0.005
D = Single Pulse
D = 0.9
D = 0.5
Package Outline Dimensions
Please see AP02002 at http://www.diodes.com/datasheets/ap02002.pdf for latest version.
Suggested Pad Layout
Please see AP02001 at http://www.diodes.com/datasheets/ap02001.pdf for the latest version.
SOT563
Dim Min Max Typ
A 0.15 0.30 0.20
B 1.10 1.25 1.20
C 1.55 1.70 1.60
D - - 0.50
G 0.90 1.10 1.00
H 1.50 1.70 1.60
K 0.55 0.60 0.60
L 0.10 0.30 0.20
M 0.10 0.18 0.11
All Dimensions in mm
Dimensions Value (in mm)
Z 2.2
G 1.2
X 0.375
Y 0.5
C1 1.7
C2 0.5
A
M
L
B C
H
K
G
D
X
Z
Y
C1
C2 C2
G
