DMN3404L
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Value Units
Drain-Source Voltage (Note 6 & 7) V
DSS
30 V
Gate-Source Voltage V
GSS
±20 V
Continuous Drain Current (Note 6) V
GS
= 10V
Steady
State
T
A
= -40°C
T
A
= +25°C
T
A
= +85°C
I
D
4.6
4.2
3.0
A
Continuous Drain Current (Note 7) V
GS
= 10V
Steady
State
T
A
= -40°C
T
A
= +25°C
T
A
= +85°C
I
D
6.2
5.8
4.0
A
Continuous Drain Current (Note 7) V
GS
= 4.5V
Steady
State
T
A
= -40°C
T
A
= +25°C
T
A
= +85°C
I
D
5.2
4.8
3.2
A
Continuous Drain Current (Note 7) V
GS
= 3V
Steady
State
T
A
= -40°C
T
A
= +25°C
T
A
= +85°C
I
D
2.2
2.0
1.0
A
Pulsed Drain Current I
DM
30 A
Thermal Characteristics
Characteristic Symbol Value Unit
Power Dissipation (Note 6) P
D
0.72 W
Thermal Resistance, Junction to Ambient @T
A
= +25°C R
θJA
173 °C/W
Power Dissipation (Note 7) P
D
1.4 W
Thermal Resistance, Junction to Ambient @T
A
= +25°C R
θJA
90 °C/W
Operating and Storage Temperature Range T
J,
T
STG
-55 to +150 °C
Notes: 6. Device mounted on FR-4 substrate PC board, 2oz copper, with minimum recommended pad layout.
7. Device mounted on FR-4 substrate PC board, 2oz copper, with thermal bias to bottom layer 1inch square copper plate.
