DMN3024SFG

Document number: DS35439 Rev. 3 - 2

1 of 7

www.diodes.com

May 2012

© Diodes Incorporated

DMN3024SFG

ADVAN

CE I

N

F

O

RM

ATI

O

N


30V N-CHANNEL ENHANCEMENT MODE MOSFET

POWERDI

®

Product Summary

V

(BR)DSS

R

DS(ON)

max

I

D

max

T

A

= 25°C

30V

23m

Ω @ V

GS

= 10V

7.5A

33m

Ω @ V

GS

= 4.5V

6.3 A




Description and Applications

This MOSFET has been designed to minimize the on-state resistance
(R

DS(on)

) and yet maintain superior switching performance, making it

ideal for high efficiency power management applications.

• Backlighting

Power Management Functions

• DC-DC

Converters

Features and Benefits

100% Unclamped Inductive Switch (UIS) test in production

• Low

R

DS(ON)

– ensures on state losses are minimized

Small form factor thermally efficient package enables higher
density end products

Occupies just 33% of the board area occupied by SO-8 enabling
smaller end product

Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)

Halogen and Antimony Free. “Green” Device (Note 3)

Qualified to AEC-Q101 Standards for High Reliability

Mechanical Data

• Case:

POWERDI3333-8

Case Material: Molded Plastic, "Green" Molding Compound.
UL Flammability Classification Rating 94V-0

Moisture Sensitivity: Level 1 per J-STD-020

• Terminal

Connections

Indicator: See diagram

Terminals: Finish

⎯ Matte Tin annealed over Copper leadframe.

Solderable per MIL-STD-202, Method 208

Weight: 0.008 grams (approximate)
















Ordering Information

(Note 4)

Part Number

Case

Packaging

DMN3024SFG-7

POWERDI3333-8

2000/Tape & Reel

DMN3024SFG-13

POWERDI3333-8

3000/Tape & Reel

Notes:

1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.

2. See http://www.diodes.com for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green" and Lead-free.



3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and
<1000ppm antimony compounds.

4. For packaging details, go to our website at http://www.diodes.com.



Marking Information









Bottom View

S

S

S

G

D

D

D

D

Pin 1

Top View

N34 = Product Type Marking Code
YYWW = Date Code Marking
YY = Last digit of year (ex: 11 = 2011)
WW = Week code (01 ~ 53)

N34

YYW

W

POWERDI3333-8

1

2

3

4

8

7

6

5

Top View

Internal Schematic
