DMN3010LSS
Document number: DS31259 Rev. 6 - 2
4 of 5
www.diodes.com
November 2008
© Diodes Incorporated
DMN3010LSS
NEW PROD
UC
T
0.001
0.01
0.1
1
r(t)
,
T
R
ANSI
EN
T
T
H
E
R
MA
L
R
ESI
S
T
AN
C
E
Fig. 8 Transient Thermal Response
t , PULSE DURATION TIME (s)
1
0.00001
0.0001
0.001
0.01
0.1
1
10
100
1,000
T - T = P * R
(t)
Duty Cycle, D = t /t
J
A
JA
1 2
θ
R
(t) = r(t) * R
R
= 88°C/W
θ
θ
θ
JA
JA
JA
P(pk)
t
1
t
2
D = 0.7
D = 0.5
D = 0.3
D = 0.1
D = 0.05
D = 0.02
D = 0.01
D = 0.005
D = Single Pulse
D = 0.9
Ordering Information
(Note 6)
Part Number
Case
Packaging
DMN3010LSS-13
SOP-8L
2500/Tape & Reel
Notes:
6. For packaging details, go to our website at http://www.diodes.com/datasheets/ap02007.pdf.
Marking Information
Package Outline Dimensions
SOP-8L
Dim
Min
Max
A
-
1.75
A1
0.08
0.25
A2
1.30
1.50
A3
0.20 Typ.
b
0.3
0.5
D
4.80
5.30
E
5.79
6.20
E1
3.70
4.10
e
1.27 Typ.
h
- 0.35
L
0.38 1.27
θ
0
°
8
°
All Dimensions in mm
Top View
Logo
Part no.
Year : "07" =2007
"08" =2008
Xth week: 01~52
1
4
8
5
N3010LS
YY WW
GAUGE PLANE
SEATING PLANE
DETAIL A
DETAIL A
E
E1
h
L
D
e
b
A2
A1
A
45
°
7
°~
9
°
A3
0.
25
4
