DMG7702SFG
Document number: DS35248 Rev. 6 - 2
2 of 8
www.diodes.com
July 2012
© Diodes Incorporated
DMG7702SFG
Marking Information
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Value Units
Drain-Source Voltage V
DSS
30 V
Gate-Source Voltage V
GSS
±20 V
Continuous Drain Current (Note 6) V
GS
= 10V
Steady
State
T
A
= +25°C
T
A
= +70°C
I
D
12
9.5
A
t<10s
T A = +25°C
T A = +70°C
I D
16.0
12.7
A
Continuous Drain Current (Note 6) V
GS
= 4.5V
Steady
State
T
A
= +25°C
T
A
= +70°C
I
D
9.5
7.5
A
t<10s
T
A
= +25°C
T A = +70°C
I
D
13.0
10.3
A
Pulsed Drain Current (10 μs pulse, duty cycle = 1%) I
DM
90 A
Maximum Continuous Body Diode Forward Current (Note 6) I
S
3.5 A
Avalanche Current (Note 7) L = 0.1mH I
AR
17 A
Repetitive Avalanche Energy (Note 7) L = 0.1mH E
AR
43 mJ
Thermal Characteristics
Characteristic Symbol Value Units
Total Power Dissipation (Note 5)
T A = +25°C
P
D
0.89
W
T
A
= +70°C 0.55
Thermal Resistance, Junction to Ambient (Note 5)
Steady state
R θJA
145
°C/W
t<10s 74
Total Power Dissipation (Note 6)
T
A
= +25°C
P
D
2.2
W
T
A
= +70°C 1.3
Thermal Resistance, Junction to Ambient (Note 6)
Steady state
R θJA
58
°C/W t<10s 31
Thermal Resistance, Junction to Case (Note 6) R θJC 11
Operating and Storage Temperature Range T
J,
T
STG
-55 to +150 °C
Notes: 5. Device mounted on FR-4 substrate PC board, 2oz copper, with minimum recommended pad layout.
6. Device mounted on FR-4 substrate PC board, 2oz copper, with 1inch square copper plate.
7. I
AR
and E
AR
rating are based on low frequency and duty cycles to keep T
J
= +25°C
G72 = Product Type Marking Code
YYWW = Date Code Marking
YY = Last digit of year (ex: 11 = 2011)
WW = Week code (01 ~ 53)
G72
YYW
W
