Diodes DMG7408SFG - Manual

POWERDI is a registered trademark of Diodes Incorporated
DMG7408SFG
Document number: DS35620 Rev. 5 - 2
1 of 6
www.diodes.com
June 2012
© Diodes Incorporated
DMG7408SFG
ADVAN
CE I
N
F
O
RM
ATI
O
N
ADVAN
CE I
N
F
O
RM
ATI
O
N
30V N-CHANNEL ENHANCEMENT MODE MOSFET
POWERDI
®
Product Summary
V
(BR)DSS
R
DS(ON)
max
I
D
max
T
A
= 25°C
30V
23m Ω @ V
GS
= 10V 7.0A
33m Ω @ V
GS = 4.5V 6.0A
Description and Applications
This MOSFET has been designed to minimize the on-state resistance
(R
DS(on)
) and yet maintain superior switching performance, making it
ideal for high efficiency power management applications.
• Backlighting
•
Power Management Functions
• DC-DC
Converters
Features and Benefits
• 100% Unclamped Inductive Switch (UIS) test in production
• Low
R DS(ON) – ensures on state losses are minimized
• Small form factor thermally efficient package enables higher
density end products
•
Occupies just 33% of the board area occupied by SO-8 enabling
smaller end product
•
Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)
•
Halogen and Antimony Free. “Green” Device (Note 3)
•
Qualified to AEC-Q101 Standards for High Reliability
Mechanical Data
• Case:
POWERDI3333-8
• Case Material: Molded Plastic, "Green" Molding Compound.
UL Flammability Classification Rating 94V-0
• Moisture Sensitivity: Level 1 per J-STD-020
• Terminal
Connections Indicator: See diagram
• Terminals:
Finish
⎯ Matte Tin annealed over Copper leadframe.
Solderable per MIL-STD-202, Method 208
•
Weight: 0.008 grams (approximate)
Ordering Information
(Note 4)
Part Number Case Packaging
DMG7408SFG-7 POWERDI3333-8 2000/Tape & Reel
DMG7408SFG-13 POWERDI3333-8 3000/Tape & Reel
Notes: 1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.
2. See http://www.diodes.com for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green" and Lead-free.
3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and
<1000ppm antimony compounds.
4. For packaging details, go to our website at http://www.diodes.com.
Marking Information
1
2
3
4
8
7
6
5
Top View
Internal Schematic
Bottom View
S
S
S
G
D
D
D
D
Pin 1
Top View
POWERDI3333-8
N34 = Product Type Marking Code
YYWW = Date Code Marking
YY = Last digit of year (ex: 11 = 2011)
WW = Week code (01 ~ 53)
N34
YYW
W
G78 = Product Type Marking Code
YYWW = Date Code Marking
YY = Last digit of year (ex: 11 = 2011)
WW = Week code (01 ~ 53)
G78
YYW
W
