DMG4468LFG

Document number: DS31857 Rev. 2 - 2

1 of 6

www.diodes.com

October 2009

© Diodes Incorporated

DMG4468LFG

NEW PROD

UC

T

N-CHANNEL ENHANCEMENT MODE MOSFET

Features

• Low

On-Resistance

Low Input Capacitance

Fast Switching Speed

Low Input/Output Leakage

Lead Free By Design/RoHS Compliant (Note 1)

"Green" Device (Note 2)

Qualified to AEC-Q101 Standards for High Reliability

Mechanical Data

• Case:

DFN3030-8

Case Material: Molded Plastic, “Green” Molding Compound.
UL Flammability Classification Rating 94V-0

Moisture Sensitivity: Level 1 per J-STD-020

Terminal Connections: See Diagram Below

Marking Information: See Page 5

Ordering Information: See Page 5

Weight: 0.0172 grams (approximate)

















Maximum Ratings

@T

A

= 25°C unless otherwise specified

Characteristic

Symbol

Value

Unit

Drain-Source Voltage

V

DSS

30 V

Gate-Source Voltage

V

GSS

±20 V

Continuous Drain Current (Note 3)

Steady

State

T

A

= 25°C

T

A

= 85°C

I

D

7.62
4.83

A

Pulsed Drain Current (Note 4)

I

DM

45.9 A




Thermal Characteristics

Characteristic Symbol

Value

Unit

Power Dissipation (Note 3)

P

D

0.99 W

Thermal Resistance, Junction to Ambient @TA = 25°C (Note 3)

R

θJA

126.7 °C/W

Operating and Storage Temperature Range

T

J

, T

STG

-55 to +150

°C

Notes:

1. No purposefully added lead.

2. Diodes Inc.'s "Green" policy can be found on our website at http://www.diodes.com/products/lead_free/index.php.

3. Device mounted on FR-4 PCB, with minimum recommended pad layout.

4. Repetitive rating, pulse width limited by junction temperature.

TOP VIEW

Internal Schematic

TOP VIEW

BOTTOM VIEW

5

6

7

8

4

3

2

1

G

S

S

S

D

BOTTOM VIEW

Pin Configuration

1

2

3

4

8

7

6

5
