DMG3402L
Document number: DS36077 Rev. 2 - 2
2 of 5
December 2013
© Diodes Incorporated
DMG3402L
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic
Symbol
Value
Unit
Drain Source Voltage
V
DSS
30
V
Gate-Source Voltage
V
GSS
12
V
Drain Current (Note 5)
I
D
4.0
A
Body-Diode Continuous Current (Note 5)
I
S
1.5
A
Thermal Characteristics
Characteristic
Symbol
Value
Unit
Total Power Dissipation (Note 5)
P
D
1.4 W
Thermal Resistance, Junction to Ambient @T
A
= +25°C (Note 5)
R
θJA
90 °C/W
Operating and Storage Temperature Range
T
J,
T
STG
-55 to +150
°C
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic
Symbol
Min
Typ
Max
Unit
Test Condition
OFF CHARACTERISTICS (Note 6)
Drain-Source Breakdown Voltage
BV
DSS
30
V
V
GS
= 0V, I
D
= 250µA
Zero Gate Voltage Drain Current
I
DSS
1
µA
V
DS
= 30V, V
GS
= 0V
Gate-Body Leakage
I
GSS
100
nA
V
GS
= ±12V, V
DS
= 0V
ON CHARACTERISTICS (Note 6)
Gate Threshold Voltage
V
GS(th)
0.6
—
1.4
V
V
DS
= V
GS
, I
D
= 250µA
Static Drain-Source On-Resistance
R
DS(ON)
—
—
—
52
65
85
mΩ
V
GS
= 10V, I
D
= 4A
V
GS
= 4.5V, I
D
= 3A
V
GS
= 2.5V, I
D
= 2A
Forward Transconductance
|Y
fs
|
6.6
S
V
DS
= 5V, I
D
= 3.1A
Source-Drain Diode Forward Voltage
V
SD
1.16 V
V
GS
= 0V, I
S
= 2.0A
DYNAMIC CHARACTERISTICS(Note 7)
Gate Resistance
R
g
2.2
Ω
V
DS
=0V, V
GS
= 0V,
f = 1MHz
Total Gate Charge (10V)
Q
g
11.7
nC
V
GS
= 10 V, V
DS
= 15V,
I
D
= 4 A
Total Gate Charge (4.5V)
Q
g
5.5
nC
V
GS
=10 V, V
DS
= 15V,
I
D
= 4 A
Gate-Source Charge
Q
gs
1.1
nC
Gate-Drain Charge
Q
gd
1.8
nC
Turn-On Delay Time
t
D(on)
1.9
ns
V
DD
= 15V, V
GEN
= 10V,
R
GEN
=3Ω, R
L
= 3.75Ω
Turn-On Rise Time
t
r
1.6
ns
Turn-Off Delay Time
t
D(off)
10.3
ns
Turn-Off Fall Time
t
f
2.0
ns
Input Capacitance
C
iss
464
pF
V
DS
= 15V, V
GS
= 0V
f = 1.0MHz
Output Capacitance
C
oss
49.5
pF
Reverse Transfer Capacitance
C
rss
43.8
pF
Notes:
5. Device mounted on FR-4 PCB. t
≤5 sec.
6. Short duration pulse test used to minimize self-heating effect.
7. Guaranteed by design. Not subject to production testing.
