background image

DMN2014LHAB

Document number: DS36441 Rev. 1 - 2

1 of 6

www.diodes.com

December 2013

© Diodes Incorporated

DMN2014LHAB

ADVAN

CE I

N

F

O

RM

ATI

O

N

D1

S1

G1

Gate Protection

Diode

D2

S2

G2

Gate Protection

Diode


DUAL N-CHANNEL ENHANCEMENT MODE MOSFET

Product Summary

V

(BR)DSS

R

DS(on) max

I

D

T

A

= +25°C

20V

13mΩ @ V

GS

= 4.5V

9.0A

14mΩ @ V

GS

= 4.0V

8.7A

17mΩ @ V

GS

= 3.1V

8.0A

18mΩ @ V

GS

= 2.5V

6.7A

28mΩ @ V

GS

= 1.8V

6.3A

Description

This new generation MOSFET has been designed to minimize the on-
state resistance (R

DS(on)

) and yet maintain superior switching

performance, making it ideal for high efficiency power management
applications.

Applications

Power management functions

 Battery

Pack

 Load

Switch

Features

 Low

On-Resistance

Low Gate Threshold Voltage

Low Input Capacitance

Fast Switching Speed

ESD Protected Gate

Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)

Halogen and Antimony Free. “Green” Device (Note 3)

Qualified to AEC-Q101 Standards for High Reliability

Mechanical Data

 Case:

U-DFN2030-6

Case Material: Molded Plastic, “Green” Molding Compound. UL
Flammability Classification Rating 94V-0

Moisture Sensitivity: Level 1 per J-STD-020

Terminal Connections: See Diagram Below

Weight: 0.012 grams (approximate)




















Ordering Information

(Note 4)

Part Number

Case

Packaging

DMN2014LHAB-7

U-DFN2030-6

3000 / Tape & Reel

Notes:

1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.

2. See http://www.diodes.com/quality/lead_free.html for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green"

and Lead-free.

3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and

<1000ppm antimony compounds.
4. For packaging details, go to our website at http://www.diodes.com/products/packages.html.


Marking Information











24W = Product Type Marking Code
YYWW = Date Code Marking
YY = Last digit of year (ex: 12 for 2012)
WW = Week code (01 to 53)

Bottom View

U-DFN2030-6

24W

Y

Y

W

W

Equivalent Circuit

Top View

ESD PROTECTED TO 2kV
