DMMT3906W
Electrical Characteristics
(@T
A
= +25°C unless otherwise specified)
Characteristic
Symbol
Min
TYP
Max
Unit
Test Condition
OFF CHARACTERISTICS
Collector-Base Breakdown Voltage
BV
CBO
-40
⎯
⎯
V
I
C
= -100
μA, I
E
= 0
Collector-Emitter Breakdown Voltage (Note 9)
BV
CEO
-40
⎯
⎯
V
I
C
= -1.0mA, I
B
= 0
Emitter-Base Breakdown Voltage
BV
EBO
-5.0
⎯
⎯
V
I
E
= -100
μA, I
C
= 0
Collector Cutoff Current
I
CEX
⎯
⎯
-50
nA
V
CE
= -30V, V
EB(OFF)
= 3.0V
Base Cutoff Current
I
BL
⎯
⎯
-50
nA
V
CE
= -30V, V
EB(OFF)
= 3.0V
ON CHARACTERISTICS (Note 9)
DC Current Gain
h
FE
60
80
100
60
30
⎯
⎯
⎯
300
⎯
⎯
⎯
I
C
= -100µA, V
CE
= -1.0V
I
C
= -1.0mA, V
CE
= -1.0V
I
C
= -10mA, V
CE
= -1.0V
I
C
= -50mA, V
CE
= - 1.0V
I
C
= -100mA, V
CE
= -1.0V
Collector-Emitter Saturation Voltage
V
CE(SAT)
⎯
⎯
-250
-400
mV
I
C
= -10mA, I
B
= -1.0mA
I
C
= -50mA, I
B
= -5.0mA
Base-Emitter Saturation Voltage
V
BE(SAT)
0.65
⎯
⎯
-850
-950
mV
I
C
= -10mA, I
B
= -1.0mA
I
C
= -50mA, I
B
= -5.0mA
MATCHING CHARACTERISTICS
DC Current Gain Matching (Note 10
)
h
FE1
/
h
FE2
⎯
1
2
%
I
C
= -2mA, V
CE
= -5V
Base-Emitter Voltage Matching (Note 11
)
V
BE1
-
V
BE2
⎯
1 2 mV
I
C
= -2mA, V
CE
= -5V
Collector-Emitter Saturation Voltage (Note 10)
V
CE(SAT)1
/
V
CE(SAT)2
⎯
1 2 %
I
C
= -10mA, I
B
= -1.0mA
Base-Emitter Saturation Voltage (Note 10)
V
BE(SAT)1
/
V
BE(SAT)2
⎯
1 2 %
I
C
= -10mA, I
B
= -1.0mA
SMALL SIGNAL CHARACTERISTICS
Output Capacitance
C
obo
⎯
⎯
4.5
pF
V
CB
= -5.0V, f = 1.0MHz, I
E
= 0
Input Capacitance
C
ibo
⎯
⎯
10.0
pF
V
EB
= -0.5V, f = 1.0MHz, I
C
= 0
Input Impedance
h
ie
2.0
⎯
12
k
Ω
V
CE
= 10V, I
C
= 1.0mA,
f = 1.0kHz
Voltage Feedback Ratio
h
re
0.1
⎯
10
x 10
-4
Small Signal Current Gain
h
fe
100
⎯
400
⎯
Output Admittance
h
oe
3.0
⎯
60
μS
Current Gain-Bandwidth Product
f
T
250
⎯
⎯
MHz
V
CE
= -20V, I
C
= -10mA,
f = 100MHz
Noise Figure
NF
⎯
⎯
4.0
dB
V
CE
= -5.0V, I
C
= -100
μA,
R
S
= 1.0k
Ω,
f = 1.0kHz
SWITCHING CHARACTERISTICS
Delay Time
t
d
⎯
⎯
35
ns
V
CC
= -3.0V, I
C
= -10mA,
V
BE(off)
= 0.5V, I
B1
= -1.0mA
Rise Time
t
r
⎯
⎯
35
ns
Storage Time
t
s
⎯
⎯
225
ns
V
CC
= -3.0V, I
C
= -10mA,
I
B1
= I
B2
= -1.0mA
Fall Time
t
f
⎯
⎯
75
ns
Note:
9. Measured under pulsed conditions. Pulse width ≤ 300µs. Duty cycle ≤ 2%.
10. Is the ratio of one transistor compared to the other transistor.
11. V
BE1
-
V
BE2
is the absolute difference of one transistor compared to the other transistor.
