MIMD10A
© Diodes Incorporated
MIMD10A MIMD10A
DUAL PRE-BIASED TRANSISTORS FOR POWER MANAGEMENT
Features
N
E
W
PP
RODROD
U
C
T T
U
C
• Epitaxial Planar Die Construction
• Built-In Biasing Resistors
• One 500mA PNP and One 100mA NPN
• Lead Free/RoHS Compliant (Note 1)
• "Green" Device (Note 3 and 4)
Mechanical Data
• Case: SOT-363
• Case Material - Molded Plastic. UL Flammability
Classification Rating 94V-0
• Moisture Sensitivity: Level 1 per J-STD-020A
• Terminals: Finish - Solderable per MIL-STD-202,
Method 208
• Lead Free Plating (Matte Tin Finish annealed over Alloy
42 leadframe).
• Marking Code: C73 See Page 4
• Ordering & Date Code: See Page 4
• Terminal Connections: See Diagram
• Weight: 0.015 grams (approximate)
P/N R1 R2
MIMD10A Tr1
Tr2 0.1K
10K
10K
-
SOT-363
Dim Min Max
A 0.10 0.30
B 1.15 1.35
C 2.00 2.20
D 0.65 Nominal
F 0.30 0.40
H 1.80 2.20
J ⎯ 0.10
K 0.90 1.00
L 0.25 0.40
M 0.10 0.25
α 0° 8 °
All Dime sions in mm n
A
M
J
L D
Maximum Ratings PNP Section Tr1
@T
A
= 25°C unless otherwise specified
Characteristic Symbol Value Unit
Supply Voltage V
CC
-50 V
Input Voltage V
IN
-5 to +5 V
Output Current I
O
-500 mA
Maximum Ratings NPN Section Tr2
@T
A
= 25°C unless otherwise specified
Characteristic Symbol Value Unit
Collector-Base Voltage V
CBO
50 V
Collector-Emitter Voltage V
CEO
50 V
Emitter-Base Voltage V
EBO
5 V
Collector Current I
C
100 mA
Maximum Ratings - Total
@T
A
= 25°C unless otherwise specified
Characteristic Symbol Value Unit
Power Dissipation (Note 2) P
d
200 mW
Operating and Storage Temperature Range T
j
, T
STG
-55 to +150 °C
Notes: 1. No purposefully added lead.
2. Mounted on FR4 PC Board with recommended pad layout at http://www.diodes.com/datasheets/ap02001.pdf.
3. Diodes Inc.'s "Green" policy can be found on our website at http://www.diodes.com/products/lead_free/index.php.
4. Product manufactured with Date Code UO (week 40, 2007) and newer are built with Green Molding Compound. Product manufactured prior to Date
Code UO are built with Non-Green Molding Compound and may contain Halogens or Sb2O3 Fire Retardants.
SCHEMATIC DIAGRAM
R
1
R
1
R
2
T
r2
T
r1
B C
H
K
E
1
C
2
B
1
C
1
E
2
B
2
F
