DIMD10A
Document number: DS30391 Rev. 5 - 2
3 of 4
September 2010
© Diodes Incorporated
DIMD10A
Typical Curves - Tr2 (continued)
0.01
0.1
1
10
100
0
1
2
3
4
8
9
10
I,
C
O
LL
E
C
T
O
R
C
U
R
R
EN
T
(mA
)
C
V , INPUT VOLTAGE (V)
Fig. 5 Collector Current vs. Input Voltage
in
5
6
7
75°C
25°C
0.001
0.1
1
10
0
10
20
30
40
50
I , COLLECTOR CURRENT (mA)
Fig. 6 Input Voltage vs. Collector Current
C
V
, I
N
PUT
VO
L
T
AG
E
(V)
in
Ordering Information
(Note 4)
Part Number
Case
Packaging
DIMD10A-7
SC-74R
3000/Tape & Reel
Notes:
4. For packaging details, go to our website at
Marking Information
Date Code Key
Year
2005
2006
2007
2008
2009
2010
2011
2012
2013
2014
2015
Code
S T U V W X Y Z A B C
Month
Jan
Feb
Mar
Apr
May
Jun
Jul
Aug
Sep
Oct
Nov
Dec
Code
1 2 3 4 5 6 7 8 9 O N D
Package Outline Dimensions
SC-74R
Dim
Min Max Typ
A
0.35 0.50 0.38
B
1.50 1.70 1.60
C
2.70 3.00 2.80
D
⎯
⎯ 0.95
H
2.90 3.10 3.00
J
0.013 0.10 0.05
K
1.00 1.30 1.10
L
0.35 0.55 0.40
M
0.10 0.20 0.15
α
0° 8°
⎯
All Dimensions in mm
C73 = Product Type Marking Code
YM = Date Code Marking
Y = Year (ex: S = 2005)
M = Month (ex: 9 = September)
C73
YM
A
M
J
L
D
B C
H
K
