DIMD10A
Document number: DS30391 Rev. 5 - 2
1 of 4
September 2010
© Diodes Incorporated
DIMD10A
DUAL PRE-BIASED TRANSISTORS FOR POWER MANAGEMENT
Features
•
Epitaxial Planar Die Construction
•
Built-In Biasing Resistors
•
One 500mA PNP and One 100mA NPN
•
Lead Free/RoHS Compliant (Note 1)
•
“Green” Devices (Note 2)
•
Qualified to AEC-Q101 Standards for High Reliability
Part Number
R1
R2
Marking
DIMD10A
Tr1
0.1K 10K
C73
Tr2 10K
-
Mechanical Data
• Case:
SC-74R
•
Case Material: Molded Plastic, “Green” Molding Compound.
UL Flammability Classification Rating 94V-0
•
Moisture Sensitivity: Level 1 per J-STD-020
•
Terminal Connections: See Diagram
•
Terminals: Finish - Matte Tin Finish annealed over Copper
leadframe. Solderable per MIL-STD-202, Method 208
•
Marking Information: See Table and Page 3
•
Ordering Information: See Page 3
•
Weight: 0.015 grams (approximate)
Maximum Ratings PNP Section Tr1
@T
A
= 25°C unless otherwise specified
Characteristic
Symbol
Value
Unit
Supply Voltage
V
CC
-50
V
Input Voltage
V
IN
-5 to +5
V
Output Current
I
O
-500
mA
Maximum Ratings NPN Section Tr2
@T
A
= 25°C unless otherwise specified
Characteristic
Symbol
Value
Unit
Collector-Base Voltage
V
CBO
50
V
Collector-Emitter Voltage
V
CEO
50
V
Emitter-Base Voltage
V
EBO
5
V
Collector Current
I
C
100
mA
Thermal Characteristics
Characteristic
Symbol
Value
Unit
Power Dissipation
P
D
300*
mW
Operating and Storage Temperature Range
T
J
, T
STG
-55 to +150
°C
* Not to exceed 200mW for either Tr1 or Tr2.
Electrical Characteristics PNP Section Tr1
@T
A
= 25°C unless otherwise specified
Characteristic
Symbol
Min
Typ
Max
Unit
Test Condition
Input Voltage
V
l(off)
-0.3
⎯
⎯
V
V
CC
= -5V, I
O
= -100
μA
V
l(on)
⎯
⎯
-1.5
V
O
= 0.3, I
O
= -100mA
Output Voltage
V
O(on)
⎯
-0.1
-0.3
V
I
O
= -100mA/-5mA
Input Current
I
l
⎯
⎯
-25
mA V
I
= -2V
Output Current
I
O(off)
⎯
⎯
-0.5
μA V
CC
= -50V, V
I
= 0V
DC Current Gain
G
l
68
⎯
⎯
⎯
⎯
Gain-Bandwidth Product*
f
T
⎯
200
⎯
MHz V
CE
= -10V, I
E
= -50mA, f = 100MHz
* Transistor - For Reference Only
Notes:
1. No purposefully added lead.
2. “Green” devices, Halogen and Antimony Free, Diodes Inc’s “Green” Policy can be found on our website at
Device Schematic
R
1
R
1
R
2
T
r2
T
r1
