Electrical Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic
Symbol
Min
Typ
Max
Unit
Test Condition
Collector-Base Breakdown Voltage
BV
CBO
50
⎯
⎯
V
I
C
= 50
μA
Collector-Emitter Breakdown Voltage
BV
CEO
50
⎯
⎯
V
I
C
= 1mA
Emitter-Base Breakdown Voltage
BV
EBO
5
⎯
⎯
V
I
E
= 720
μA, DDTC114GCA
I
E
= 330
μA, DDTC124GCA
I
E
= 160
μA, DDTC144GCA
I
E
= 72
μA, DDTC115GCA
Collector Cutoff Current
I
CBO
⎯
⎯
0.5
μA V
CB
= 50V
Emitter Cutoff Current
DDTC114GCA
DDTC124GCA
DDTC144GCA
DDTC115GCA
I
EBO
300
140
65
30
⎯
580
260
130
58
μA V
EB
= 4V
Collector-Emitter Saturation Voltage
V
CE(sat)
⎯
⎯
0.3
V
I
C
= 10mA, I
B
= 0.5mA
DC Current Transfer Ratio
DDTC114GCA
DDTC124GCA
DDTC144GCA
DDTC115GCA
h
FE
30
56
68
82
⎯
⎯
⎯ I
C
= 5mA, V
CE
= 5V
Bleeder Resistor (R
2
) Tolerance
ΔR
2
-30
⎯
+30
%
⎯
Gain-Bandwidth Product*
f
T
⎯
250
⎯
MHz
V
CE
= 10V, I
E
= -5mA,
f = 100MHz
* Transistor - For Reference Only
