Diodes DDTC (R2-ONLY SERIES) CA User Manual
Ddtc, R2-only series), Features

DDTC
(R2-ONLY SERIES)
CA
DS30332 Rev. 6 - 2
1 of 4
www.diodes.com
DDTC (R2-ONLY SERIES) CA
© Diodes Incorporated
NPN PRE-BIASED SMALL SIGNAL SOT-23
Features
•
Epitaxial Planar Die Construction
•
Complementary PNP Types Available (DDTA)
•
Built-In Biasing Resistor, R2 only
•
Lead, Halogen and Antimony Free, RoHS
Compliant "Green" Device (Notes 2 and 3)
Mechanical Data
•
Case: SOT-23
•
Case Material: Molded Plastic. UL Flammability
Classification Rating 94V-0
•
Moisture Sensitivity: Level 1 per J-STD-020D
•
Terminal Connections: See Diagram
•
Terminals: Solderable per MIL-STD-202, Method 208
•
Lead Free Plating (Matte Tin Finish annealed over
Alloy 42 leadframe).
•
Marking: Date Code and Marking Code (See Table
Below & Page 4)
•
Ordering Information: See Page 4
•
Weight: 0.008 grams (approximate)
P/N
R2 (NOM)
MARKING
DDTC114GCA
DDTC124GCA
DDTC144GCA
DDTC115GCA
10K
Ω
22K
Ω
47K
Ω
100K
Ω
N26
N27
N28
N29
SOT-23
U
C
T
A
E
J
L
TOP VIEW
M
NEW PROD
Dim
Min
Max
A
0.37
0.51
B
1.20
1.40
C
2.30
2.50
D
0.89
1.03
E
0.45
0.60
G
1.78
2.05
H
2.80
3.00
J
0.013
0.10
K
0.903
1.10
L
0.45
0.61
M
0.085
0.180
α
0
°
8
°
All Dimensions in mm
Maximum Ratings
@T
A
= 25°C unless otherwise specified
Characteristic
Symbol
Value
Unit
Collector-Base Voltage
V
CBO
50
V
Collector-Emitter Voltage
V
CEO
50
V
Emitter-Base Voltage
V
EBO
5
V
Collector Current
I
C
(Max)
100
mA
Power Dissipation
P
D
200
mW
Thermal Resistance, Junction to Ambient Air (Note 1)
R
θJA
625
°C/W
Operating and Storage Temperature Range
T
J
, T
STG
-55 to +150
°C
Notes:
1. Mounted on FR4 PC Board with recommended pad layout as shown on Diodes Inc., suggested pad layout document AP02001, which can be found on
our website at http://www.diodes.com/datasheets/ap02001.pdf
2. No purposefully added lead. Halogen and Antimony Free.
3. Product manufactured with Data Code V9 (week 33, 2008) and newer are built with Green Molding Compound. Product manufactured prior to Date
Code V9 are built with Non-Green Molding Compound and may contain Halogens or Sb
2
O
3
Fire Retardants.
B
R
2
SCHEMATIC DIAGRAM
E
C
B
C
H
G
D
K
C
B
E
