DDTC(R1 = R2 SERIES) CA
Document number: DS30329 Rev. 12 - 2
2 of 5
www.diodes.com
November 2013
© Diodes Incorporated
DDTC(R1 = R2 SERIES) CA
Absolute Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Value Unit
Supply Voltage V
CC
50 V
Input Voltage
DDTC123ECA
DDTC143ECA
DDTC114ECA
DDTC124ECA
DDTC144ECA
DDTC115ECA
V
IN
-10 to +12
-10 to +30
-10 to +40
-10 to +40
-10 to +40
-10 to +40
V
Output Current
DDTC123ECA
DDTC143ECA
DDTC114ECA
DDTC124ECA
DDTC144ECA
DDTC115ECA
I
O
100
100
50
30
30
20
mA
Output Current I
C
(Max) 100 mA
Thermal Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Value Unit
Power Dissipation (Note 6) P
D
200 mW
Thermal Resistance, Junction to Ambient Air (Note 6) R
θJA
625 °C/W
Operating and Storage Temperature Range T
J
, T
STG
-55 to +150 °C
Note: 6. Mounted on FR4 PC Board with minimum recommended pad layout
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Min Typ Max Unit Test Condition
Input Voltage
V
l(off)
0.5 1.1 
V
V
CC
= 5V, I
O
= 100μA
V
l(on)
 1.9 3
V
O
= 0.3V, I
O
= 20mA, DDTC123ECA
V
O
= 0.3V, I
O
= 20mA, DDTC143ECA
V
O
= 0.3V, I
O
= 10mA, DDTC114ECA
V
O
= 0.3V, I
O
= 5mA, DDTC124ECA
V
O
= 0.3V, I
O
= 2mA, DDTC144ECA
V
O
= 0.3V, I
O
= 1mA, DDTC115ECA
Output Voltage V
O(on)
 0.1 0.3 V
I
O
/I
l
= 10mA/0.5mA DDTC123ECA
I
O
/I
l
= 10mA/0.5mA DDTC143ECA
I
O
/I
l
= 10mA/0.5mA DDTC114ECA
I
O
/I
l
= 10mA/0.5mA DDTC124ECA
I
O
/I
l
= 10mA/0.5mA DDTC144ECA
I
O
/I
l
= 5mA/0.25mA DDTC115ECA
Input Current
DDTC123ECA
DDTC143ECA
DDTC114ECA
DDTC124ECA
DDTC144ECA
DDTC115ECA
I
l
 
3.8
1.8
0.88
0.36
0.18
0.15
mA V
I
= 5V
Output Current I
O(off)
  0.5 μA V
CC
= 50V, V
I
= 0V
DC Current Gain
DDTC123ECA
DDTC143ECA
DDTC114ECA
DDTC114ECAQ
DDTC124ECA
DDTC144ECA
DDTC144ECAQ
DDTC115ECA
G
l
20
20
30
35
56
68
80
82
  
V
O
= 5V, I
O
= 20mA
V
O
= 5V, I
O
= 10mA
V
O
= 5V, I
O
= 5mA
V
O
= 5V, I
O
= 5mA
V
O
= 5V, I
O
= 5mA
V
O
= 5V, I
O
= 5mA
V
O
= 5V, I
O
= 5mA
V
O
= 5V, I
O
= 5mA
Input Resistor Tolerance R
1
-30  +30 % 
Resistance Ratio Tolerance R
2
/R
1
0.8 1 1.2 % 
Gain-Bandwidth Product (Note 7) f
T
 250  MHz
V
CE
= 10V, I
E
= 5mA,
f = 100MHz
Note: 7. Transistor - For Reference Only
