Electrical Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic
Symbol
Min
Typ
Max Unit
Test Condition
Collector-Base Breakdown Voltage
BV
CBO
-50
⎯
⎯
V
I
C
= -50
μA
Collector-Emitter Breakdown Voltage
BV
CEO
-50
⎯
⎯
V
I
C
= -1mA
Emitter-Base Breakdown Voltage
BV
EBO
5
⎯
⎯
V
I
E
= -720
μA, DDTA114GE
I
E
= -330
μA, DDTA124GE
I
E
= -160
μA, DDTA144GE
I
E
= -72
μA, DDTA115GE
Collector Cutoff Current
I
CBO
⎯
⎯
-0.5
μA V
CB
= -50V
Emitter Cutoff Current
DDTA114GE
DDTA124GE
DDTA144GE
DDTA115GE
I
EBO
-300
-140
-65
-30
⎯
-580
-260
-130
-58
μA V
EB
= -4V
Collector-Emitter Saturation Voltage
V
CE(sat)
⎯
⎯
-0.3
V
I
C
= -10mA, I
B
= -0.5mA
DC Current Transfer Ratio
DDTA114GE
DDTA124GE
DDTA144GE
DDTA115GE
h
FE
30
56
68
82
⎯
⎯
⎯ I
C
= -5mA, V
CE
= -5V
Bleeder Resistor (R
2
) Tolerance
ΔR
2
-30
⎯
+30
%
⎯
Gain-Bandwidth Product*
f
T
⎯
250
⎯
MHz V
CE
= -10V, I
E
= 5mA,
f = 100MHz
* Transistor - For Reference Only
