DDTA (R1 = R2 SERIES) CA
Absolute Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Value
Unit
Supply Voltage
V
CC
50 V
Input Voltage
DDTA123ECA
DDTA143ECA
DDTA114ECA
DDTA124ECA
DDTA144ECA
DDTA115ECA
V
IN
+10 to –12
+10 to –30
+10 to –40
+10 to –40
+10 to –40
+10 to –40
V
Output Current
DDTA123ECA
DDTA143ECA
DDTA114ECA
DDTA124ECA
DDTA144ECA
DDTA115ECA
I
O
-100
-100
-50
-30
-30
-20
mA
Output Current
I
C
(Max)
-100 mA
Thermal Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Value
Unit
Power Dissipation (Note 6)
P
D
200 mW
Thermal Resistance, Junction to Ambient Air (Note 6)
R
JA
625 °C/W
Operating and Storage Temperature Range
T
J
, T
STG
-55 to +150
°C
Notes:
6. Mounted on FR4 PC Board with minimum recommended pad layout
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Min
Typ
Max
Unit
Test
Condition
Input Voltage
V
l(off)
-0.5 -1.1
V
V
CC
= -5V, I
O
= -100
A
V
l(on)
-1.9 -3
V
O
= -0.3V, I
O
= -20mA, DDTA123ECA
V
O
= -0.3V, I
O
= -20mA, DDTA143ECA
V
O
= -0.3V, I
O
= -10mA, DDTA114ECA
V
O
= -0.3V, I
O
= -5mA, DDTA124ECA
V
O
= -0.3V, I
O
= -2mA, DDTA144ECA
V
O
= -0.3V, I
O
= -1mA, DDTA115ECA
Output Voltage
V
O(on)
-0.1 -0.3
V
I
O
/I
l
= -10mA/-0.5mA DDTA123ECA
I
O
/I
l
= -10mA/-0.5mA DDTA143ECA
I
O
/I
l
= -10mA/-0.5mA DDTA114ECA
I
O
/I
l
= -10mA/-0.5mA DDTA124ECA
I
O
/I
l
= -10mA/-0.5mA DDTA144ECA
I
O
/I
l
= -5mA/-0.25mA DDTA115ECA
Input Current
DDTA123ECA
DDTA143ECA
DDTA114ECA
DDTA124ECA
DDTA144ECA
DDTA115ECA
I
l
-3.8
-1.8
-0.88
-0.36
-0.18
-0.15
mA
V
I
= -5V
Output Current
I
O(off)
-0.5
A
V
CC
= -50V, V
I
= 0V
DC Current Gain
DDTA123ECA
DDTA143ECA
DDTA114ECA
DDTA124ECA
DDTA144ECA
DDTA115ECA
G
l
20
20
30
56
68
82
V
O
= -5V, I
O
= -20mA
V
O
= -5V, I
O
= -10mA
V
O
= -5V, I
O
= -5mA
V
O
= -5V, I
O
= -5mA
V
O
= -5V, I
O
= -5mA
V
O
= -5V, I
O
= -5mA
Input Resistor Tolerance
R
1
-30
+30 %
Resistance Ratio Tolerance
R
2
/R
1
0.8 1 1.2 %
Gain-Bandwidth Product (Note 7)
f
T
250
MHz
V
CE
= -10V, I
E
= -5mA,
f = 100MHz
Note:
7. Transistor - For Reference Only
