Maximum Ratings
(@T A = +25°C, unless otherwise specified.)
Characteristic Symbol Value Unit
Collector-Base Voltage V CBO
-400 V
Collector-Emitter Voltage V
CEO
-400 V
Emitter-Base Voltage V
EBO
-7 V
Continuous Collector Current I C
-200 mA
Thermal Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Value Unit
Power Dissipation
(Note 5)
P
D
2 W
(Note 6) 3 W
Thermal Resistance, Junction to Ambient
(Note 5)
R
θ JA
62.5 °
C/W
(Note 6) 41.7 ° C/W
Thermal Resistance, Junction to Leads (Note 7) R
θ JL
19.41 ° C/W
Operating and Storage Temperature Range T
J,
T
STG
-55 to +150 °
C
Notes: 5. For a device surface mounted on 25mm X 25mm FR4 PCB with high coverage of single sided 1 oz copper, in still air conditions; device measured when
operating in steady state condition.
6. Same as note (5), except the device is mounted on 50mm X 50mm single sided 2oz weight copper.
7. Thermal resistance from junction to solder-point (at the end of the collector lead).
