FMMT625
Document number: DS33237 Rev. 5 - 2
4 of 7
September 2012
© Diodes Incorporated
A Product Line of
Diodes Incorporated
FMMT625
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Min
Typ
Max
Unit
Test
Condition
Collector-Base Breakdown Voltage
BV
CBO
150 300 -
V I
C
= 100µA
Collector-Emitter Breakdown Voltage (Note 9)
BV
CEO
150 175 -
V I
C
= 1mA
Emitter-Base Breakdown Voltage
BV
EBO
5 8.3 -
V
I
E
= 100µA
Collector Cut-off Current
I
CBO
- -
100
nA
V
CB
=130V
Emitter Cut-off Current
I
EBO
- -
100
nA
V
EB
= 5V
Collector Emitter Cut-off Current
I
CES
- -
100
nA
V
CES
=130V
Static Forward Current Transfer Ratio (Note 9)
h
FE
200
300
30
-
400
450
45
15
-
-
-
-
-
I
C
= 10mA, V
CE
= 10V
I
C
= 200mA, V
CE
= 10V
I
C
= 1A, V
CE
= 10V
I
C
= 3A, V
CE
= 10V
Collector-Emitter Saturation Voltage (Note 9)
V
CE(sat)
-
-
-
26
110
180
50
200
300
mV
I
C
=0.1A, I
B
= 10mA
I
C
=0.1A, I
B
= 1mA
I
C
=1A, I
B
= 50mA
Base-Emitter Saturation Voltage (Note 9)
V
BE(sat)
- 0.85
1.0 V
I
C
=1A, I
B
= 50mA
Base-Emitter Saturation Voltage (Note 9)
V
BE(on)
- 0.74
1.0 V
I
C
=1A, V
CE
= 10V
Transition Frequency
f
T
100 135 -
MHz
I
C
= 50mA, V
CE
= 10V,
f=100MHz
Collector Output Capacitance
C
obo
- 6 10 pF
V
CB
= 10V, f=1MHz
Turn-On Time
t
(on)
- 160 - ns
V
CC
= 50V, I
C
= 500mA,
I
B1
= -I
B2
= 50mA
Turn-Off Time
t
(off)
- 1500 -
ns
Notes:
9. Measured under pulsed conditions. Pulse width
≤ 300µs. Duty cycle ≤ 2%
