FMMT634
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Min Typ Max Unit Test Condition
Collector-Base Breakdown Voltage BV
CBO
120 170 - V I
C
= 100µA
Collector-Emitter Breakdown Voltage (Note 9) BV
CEO
100 115 - V I
C
= 10mA
Emitter-Base Breakdown Voltage BV
EBO
12 16 - V I
E
= 100µA
Collector Cut-off Current I
CBO
- <1 10 nA V
CB
= 80V
Emitter Cut-off Current I
EBO
- <1 10 nA V
EB
= 7V
Collector Emitter Cut-off Current I
CES
- <1 100 nA V
CES
= 80V
Static Forward Current Transfer Ratio (Note 9) h
FE
-
20k
15k
5k
-
-
50k
60k
40k
14k
24k
600 -
-
-
-
-
-
-
I
C
= 10mA, V
CE
= 5V
I
C
= 100mA, V
CE
= 5V
I
C
= 1A, V
CE
= 5V
I
C
= 2A, V
CE
= 5V
I
C
= 1A, V
CE
= 2V
I
C
= 5A, V
CE
= 5V
Collector-Emitter Saturation Voltage (Note 9) V
CE(sat)
-
-
-
-
-
- 0.67
0.72
0.75
0.82
0.68
0.85 0.75
0.80
0.85
0.93
-
0.96
V
I
C
= 100mA, I
B
= 1mA
I
C
= 250mA, I
B
= 1mA
I
C
= 500mA, I
B
= 5mA
I
C
= 900mA, I
B
= 5mA
I
C
= 900mA, I
B
= 5mA, T
J
=+150°C
I
C
= 1A, I
B
= 5mA
Base-Emitter Saturation Voltage (Note 9) V
BE(sat)
- 1.5 1.65 V I
C
= 1A, I
B
= 5mA
Base-Emitter Turn-On Voltage (Note 9) V
BE(on)
- 1.33 1.50 V I
C
= 1A, V
CE
= 5V
Transition Frequency f
T
- 140 - MHz
I
C
= 50mA, V
CE
= 10V,
f = 100MHz
Output Capacitance C
obo
- 9 20 pF V
CB
= 10V, f = 1MHz
Turn-On Time t
(on)
- 290 - ns V
CC
= 20V, I
C
= 500mA,
I
B1
= -I
B2
= 1mA Turn-Off Time t
(off)
- 2,400 - ns
Notes: 9. Measured under pulsed conditions. Pulse width ≤ 300µs. Duty cycle ≤ 2%
