FCX593
Da
tasheet Number: DS33063 Rev. 5 - 2
4 of 7
January 2014
© Diodes Incorporated
FCX593
A Product Line of
Diodes Incorporated
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Min
Typ
Max
Unit
Test
Condition
Collector-Base Breakdown Voltage
BV
CBO
-120 — — V
I
C
= -100µA
Collector-Emitter Breakdown Voltage (Note 11)
BV
CEO
-100 — — V
I
C
= -10mA
Emitter-Base Breakdown Voltage
BV
EBO
-7 — — V
I
E
= -100µA
Collector Cutoff Current
I
CBO
— — -100
nA
V
CB
= -100V
Emitter Cutoff Current
I
EBO
— — -100
nA
V
EB
= -5V
Emitter Cutoff Current
I
CES
— — -100
nA
V
CES
= -100V
DC current transfer Static ratio (Note 11)
h
FE
100
100
100
50
—
—
—
300
—
—
I
C
= -1mA, V
CE
= -5V
I
C
= -250mA, V
CE
= -5V
I
C
= -500mA, V
CE
= -5V
I
C
= -1A, V
CE
= -5V
Collector-Emitter Saturation Voltage (Note 11)
V
CE(sat)
— —
-0.2
-0.3
V
I
C
= -250mA, I
B
= -25mA
I
C
= -500mA, I
B
= -50mA
Base-Emitter Saturation Voltage (Note 11)
V
BE(sat)
— — -1.1 V
I
C
= -500mA, I
B
= -50mA
Base-Emitter Turn-on Voltage (Note 11)
V
BE(on)
— — -1.0 V
I
C
= -1mA, V
CE
= -5V
Transitional Frequency
f
T
50 — — MHz
I
E
= -50mA, V
CE
= -10V
f = 100MHz
Output capacitance
C
obo
— — 5 pF
V
CB
= -10V, f = 1MHz,
Note:
11. Measured under pulsed conditions. Pulse width ≤ 300μs. Duty cycle ≤ 2%.
