Maximum Ratings
@T
A
= 25°C unless otherwise specified
Characteristic Symbol
Value
Unit
Collector-Base Voltage
V
CBO
200 V
Collector-Emitter Voltage
V
CEO
100 V
Emitter-Base Voltage
V
EBO
7 V
Continuous Collector Current
I
C
6 A
Peak Pulse Current
I
CM
10 A
Thermal Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic Symbol
Value
Unit
Power Dissipation
(Note 4)
P
D
3.2
W
(Note 5)
1.7
(Note 6)
0.74
Thermal Resistance, Junction to Ambient
(Note 4)
R
θJA
39
°C/W
(Note 5)
75
(Note 6)
169
Thermal Resistance, Junction to Collector Terminal
R
θJT
5.6 °C/W
Operating and Storage Temperature Range
T
J
, T
STG
-55 to +150
°C
Notes:
4. Device mounted on FR-4 PCB, single sided 2 oz. copper, collector pad dimensions 50mm x 50mm.
5. Device mounted on FR-4 PCB, single sided 1 oz. copper, collector pad dimensions 25mm x 25mm.
6. Device mounted on FR-4 PCB, single sided 1 oz. copper, minimum recommended pad layout.
