DPLS160

LOW V

CE(SAT)

PNP SURFACE MOUNT TRANSISTOR

Features

Epitaxial Planar Die Construction

Complementary NPN Type Available (DNLS160)

Surface Mount Package Suited for Automated Assembly

Lead Free/RoHS Compliant (Note 1)

"Green Device" (Note 2)

Qualified to AEC-Q101 Standards for High Reliability

Mechanical Data

Case: SOT-23

Case Material: Molded Plastic, “Green” Molding
Compound. UL Flammability Classification Rating 94V-0

Moisture Sensitivity: Level 1 per J-STD-020D

Terminals: Finish

⎯ Matte Tin annealed over Copper

leadframe. Solderable per MIL-STD-202, Method 208

Marking Information: See Page 4

Ordering Information: See Page 4

Weight: 0.008 grams (approximate)

NEW PRODUCT

SOT-23

E

B

C

Schematic and Pin Configuration

Maximum Ratings

@T

A

= 25°C unless otherwise specified

Characteristic Symbol

Value

Unit

Collector-Base Voltage

V

CBO

-80 V

Collector-Emitter Voltage

V

CEO

-60 V

Emitter-Base Voltage

V

EBO

-5 V

Collector Current - Continuous

I

C

-1 A

Peak Pulse Collector Current

I

CM

-2 A

Base Current (DC)

I

B

-300 mA

Thermal Characteristics

Characteristic Symbol

Value

Unit

Power Dissipation (Note 3) @ T

A

= 25

°C P

D

300 mW

Thermal Resistance, Junction to Ambient (Note 3) @ T

A

= 25

°C

R

θJA

417

°C/W

Operating and Storage Temperature Range

T

J

, T

STG

-55 to +150

°C

Notes:

1. No purposefully added lead.
2. Diode’s Inc.’s “Green” policy can be found on our website at http://www.diodes.com/products/lead_free/index.php.
3. Device mounted on FR-4 PCB, 1 inch x 0.85 inch x 0.062 inch; pad layout as shown on page 4 or in Diodes Inc. suggested pad layout document
AP02001, which can be found on our website at http://www.diodes.com/datasheets/ap02001.pdf.






















DS31389 Rev. 4 - 2

1 of 4

www.diodes.com

DPLS160

© Diodes Incorporated

Please click here to visit our online spice models database.
