FMMT619
Document number: DS33236 Rev. 8 - 2
4 of 7
October 2012
© Diodes Incorporated
A Product Line of
Diodes Incorporated
FMMT619
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Min
Typ
Max
Unit
Test
Condition
OFF CHARACTERISTICS
Collector-Base Breakdown Voltage
BV
CBO
50 190 -
V I
C
= 100µA
Collector-Emitter Breakdown Voltage (Note 9)
BV
CEO
50 65 -
V
I
C
= 10mA
Emitter-Base Breakdown Voltage
BV
EBO
7 8.3 -
V
I
E
= 100µA
Collector Cut-off Current
I
CBO
- -
100
nA
V
CB
= 40V
Emitter Cut-off Current
I
EBO
- -
100
nA
V
EB
= 6V
Collector Emitter Cut-off Current
I
CES
- -
100
nA
V
CES
= 40V
ON CHARACTERISTICS (Note 9)
Static Forward Current Transfer Ratio
h
FE
200
300
200
100
-
400
450
400
225
40
-
-
-
-
-
-
I
C
= 10mA, V
CE
= 2V
I
C
= 200mA, V
CE
= 2V
I
C
= 1A, V
CE
= 2V
I
C
= 2A, V
CE
= 2V
I
C
= 6A, V
CE
= 2V
Collector-Emitter Saturation Voltage
V
CE(sat)
-
-
-
10
125
150
20
200
220
mV
I
C
= 0.1A, I
B
= 10mA
I
C
= 1A, I
B
= 10mA
I
C
= 2A, I
B
= 50mA
Base-Emitter Saturation Voltage
V
BE(sat)
- 0.87
1.0 V
I
C
= 2A, I
B
= 50mA
Base-Emitter Saturation Voltage
V
BE(on)
- 0.82
1.0 V
I
C
= 2A, V
CE
= 2V
SMALL SIGNAL CHARACTERISTICS
Transition Frequency
f
T
100 165 -
MHz
I
C
= 50mA, V
CE
= 10V,
f = 100MHz
Collector Output Capacitance
C
obo
- 12 20 pF
V
CB
= 10V, f = 1MHz
Turn-On Time
t
(on)
- 170 - ns
V
CC
= 10V, I
C
= 1A,
I
B1
= -I
B2
= 10mA
Turn-Off Time
t
(off)
- 750 - ns
Notes:
9. Measured under pulsed conditions. Pulse width
≤ 300µs. Duty cycle ≤ 2%
