FMMT619
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Value Unit
Collector-Base Voltage V
CBO
50 V
Collector-Emitter Voltage V CEO
50 V
Emitter-Base Voltage V
EBO
7 V
Continuous Collector Current I
C
2 A
Peak Pulse Current I CM
6 A
Base Current I
B
500 mA
Thermal Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Value Unit
Power Dissipation (Note 6) P D
625 mW
Power Dissipation (Note 7) P
D
806 mW
Thermal Resistance, Junction to Ambient (Note 6) R θJA 200 °C/W
Thermal Resistance, Junction to Ambient (Note 7) R θJA 155 °C/W
Thermal Resistance, Junction to Leads (Note 8) R θJL 194 °C/W
Operating and Storage Temperature Range T
J,
T
STG
-55 to +150
°C
Notes: 6. For a device surface mounted on 25mm X 25mm FR4 PCB with high coverage of single sided 1 oz copper, in still air conditions; the device is measured
when operating in a steady-state condition.
7. Same as note 6, except the device is measured at t
≤ 5 sec.
8. Thermal resistance from junction to solder-point (at the end of the collector lead).
