ELECTRICAL CHARACTERISTICS (at T
amb
= 25°C unless otherwise stated).
PARAMETER SYMBOL MIN. TYP. MAX. UNIT CONDITIONS.
Collector-Base
Breakdown Voltage V
(BR)CBO
80 130 V I
C
=100
µ
A
Collector-Emitter
Breakdown Voltage V
CES
80 130 V I
C
=100
µ
A *
Collector-Emitter
Breakdown Voltage V
CEO
25 30 V
I
C
=10mA
Collector-Emitter
Breakdown Voltage V
CEV
80 130 V I
C
=100
µ
A, V
EB
=1V
Emitter-Base Breakdown
Voltage V
(BR)EBO
5 9 V I
E
=100
µ
A
Collector Cut-Off Current I
CBO
0.3 10 nA V
CB
=35V
Emitter Cut-Off Current I
EBO
0.3 10 nA V
EB
=4V
Collector Emitter Cut-Off
Current I
CES
0.3 10 nA V
CES
=35V
Collector-Emitter
Saturation Voltage V
CE(sat)
35
70
180
250 60
100
250
330 mV
mV
mV
mV I
C
=0.5A, I
B
=10mA*
I
C
=1A, I
B
=10mA*
I
C
=3A, I
B
=30mA*
I
C
=5A, I
B
=50mA*
Base-Emitter
Saturation Voltage V
BE(sat)
950 1050 mV I
C
=5A, I
B
=50mA*
Base-Emitter Turn-On
Voltage V
BE(on)
900 1000 mV I
C
=5A, V
CE
=2V*
Static Forward Current
Transfer Ratio h
FE
280
300
300
180
40 440
450
450
280
80
1200
I
C
=10mA, V
CE
=2V*
I
C
=0.5A, V
CE
=2V*
I
C
=1A, V
CE
=2V*
I
C
=5A, V
CE
=2V*
I
C
=20A, V
CE
=2V*
Transition Frequency f
T
180 MHz I
C
=50mA, V
CE
=10V
f=100MHz
Output Capacitance C
obo
45 60 pF V
CB
=10V, f=1MHz
Turn-on Time t
on
125 ns I
C
=4A, I
B
=40mA, V
CC
=10V
Turn-off Time t
off
380 ns
*Measured under pulsed conditions. Pulse width=300
µ
s. Duty cycle
≤
2%
FZT1049A
