Electrical characteristics, Fmmt589, A product line of diodes incorporated – Diodes FMMT589 User Manual
Page 4
FMMT589
Document number: DS33103 Rev. 7 - 2
4 of 7
November 2013
© Diodes Incorporated
FMMT589
A Product Line of
Diodes Incorporated
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Min
Typ
Max
Unit
Test
Condition
OFF CHARACTERISTICS
Collector-Base Breakdown Voltage
BV
CBO
-50
V
I
C
= -100μA
Collector-Emitter Breakdown Voltage (Note 8)
BV
CEO
-30
V
I
C
= -10mA
Emitter-Base Breakdown Voltage
BV
EBO
-7
V
I
E
= -100μA
Collector Cutoff Current
I
CBO
-100 nA
V
CB
= -30V
Collector-Emitter Cutoff Current
I
CES
-100 nA
V
CES
= -30V
Emitter Cutoff Current
I
EBO
-100 nA
V
EB
= -5.6V
ON CHARACTERISTICS (Note 8)
DC Current Gain
h
FE
100
100
80
40
300
I
C
= -1mA, V
CE
= -2V
I
C
= -500mA, V
CE
= -2V
I
C
= -1A, V
CE
= -2V
I
C
= -2A, V
CE
= -2V
Collector-Emitter Saturation Voltage
V
CE(sat)
-0.25
-0.35
-0.65
V
I
C
= -0.5A, I
B
= -50mA
I
C
= -1A, I
B
= -100mA
I
C
= -2A, I
B
= -200mA
Base-Emitter Saturation Voltage
V
BE(sat)
-1.2 V
I
C
= -1A, I
B
= -100mA
Base-Emitter Turn-On Voltage
V
BE(on)
-1.1 V
I
C
= -1A, V
CE
= -2V
SMALL SIGNAL CHARACTERISTICS
Output Capacitance
C
obo
15 pF
V
CB
= -10V, f = 1MHz
Current Gain-Bandwidth Product
f
T
100
MHz
V
CE
= -5V, I
C
= -100mA,
f = 100MHz
Notes:
8. Measured under pulsed conditions. Pulse width
300µs. Duty cycle 2%
