FMMT489
A Product Line of
Diodes Incorporated
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Value Unit
Collector-Base Voltage V
CBO
50 V
Collector-Emitter Voltage V
CEO
30 V
Emitter-Base Voltage V EBO
7 V
Continuous Collector Current I
C
1 A
Peak Pulse Current I
CM
4 A
Base Current I
B
200 mA
Thermal Characteristics
(@T A = +25°C, unless otherwise specified.)
Characteristic Symbol Value Unit
Power Dissipation (Note 5) P
D
500 mW
Thermal Resistance, Junction to Ambient (Note 5) R
θJA
250 °C/W
Thermal Resistance, Junction to Lead (Note 6) R θJL 197 °C/W
Operating and Storage Temperature Range T
J,
T
STG
-55 to +150 °C
ESD Ratings
(Note 7)
Characteristic Symbol Value Unit JEDEC Class
Electrostatic Discharge - Human Body Model ESD HBM ≥ 4,000 V 3A
Electrostatic Discharge - Machine Model ESD MM ≥ 400 V C
Notes: 5. For a device mounted with the collector lead on 15mm X 15mm 1oz weight copper that is on a single-sided FR4 PCB; device is measured under still air
conditions whilst operating in a steady-state.
6. Thermal resistance from junction to solder-point (at the end of the collector lead).
7. Refer to JEDEC specification JESD22-A114 and JESD22-A115.
