Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Min Typ. Max Unit Test Condition
Collector-Base Breakdown Voltage BV
CBO
-40 - - V I
C
= -100µA
Collector-Emitter Breakdown Voltage (Note 8) BV
CEO
-40 - - V I
C
= -10mA
Emitter-Base Breakdown Voltage BV
EBO
-7 - - V I
E
= -100µA
Collector Cutoff Current I
CBO
- - -100 nA V
CB
= -30V
Emitter Cutoff Current I
EBO
- - -100 nA V
EB
= -4V
Emitter Cutoff Current I
CES
- - -100 nA V
CES
= -30V
DC current transfer Static ratio (Note 8) h
FE
300
300
250
160
30
-
-
-
-
- -
800
-
-
- -
I C = -1mA, V CE = -5V
I
C
= -100mA, V
CE
= -5V
I
C
= -500mA, V
CE
= -5V
I
C
= -1A, V
CE
= -5V
I
C
= -2A, V
CE
= -5V
Collector-Emitter Saturation Voltage (Note 8) V CE(sat)
-
-
-
-
-0.2
-0.35
-0.5
V
I
C
= -100mA, I
B
= -1mA
I C = -500mA, I B = -20mA
I
C
= -1A, I
B
= -100mA
Base-Emitter Saturation Voltage (Note 8) V
BE(sat)
- - -1.1 V I
C
= -1A, I
B
= -50mA
Base-Emitter Turn-on Voltage (Note 8) V
BE(on)
- - -1.0 V I
C
= -1A, V
CE
= -5V
Transitional Frequency f
T
150 - - MHz
I E = -50mA, V CE = -10V
f = 100MHz
Output capacitance C
obo
- - 10 pF V
CB
= -10V, f = 1MHz,
Notes: 8. Measured under pulsed conditions. Pulse width ≤ 300μs. Duty cycle ≤ 2%.
