FCX591A
Da
tasheet Number: DS33062 Rev. 6 - 2
2 of 7
www.diodes.com
October 2012
© Diodes Incorporated
FCX591A
A Product Line of
Diodes Incorporated
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Limit Unit
Collector-Base Voltage V
CBO
-40 V
Collector-Emitter Voltage V
CEO
-40 V
Emitter-Base Voltage V
EBO
-7 V
Continuous Collector Current I
C
-1 A
Peak Pulse Current I
CM
-2 A
Peak Base Current I B
-200 mA
Thermal Characteristics
Characteristic Symbol Value Unit
Power Dissipation (Note 5) P
D
1 W
Thermal Resistance, Junction to Ambient Air (Note 5) R θJA 125
°C/W
Thermal Resistance, Junction to Leads (Note 6) R θJL 10.01 °C/W
Operating and Storage Temperature Range T
J,
T
STG
-65 to +150 °C
ESD Ratings
(Note 7)
Characteristic Symbol Value Unit JEDEC Class
Electrostatic Discharge - Human Body Model ESD HBM ≥ 8,000 V 3B
Electrostatic Discharge - Machine Model ESD MM ≥ 400 V C
Notes: 5. For a device surface mounted on 15mm X 15mm FR4 PCB with high coverage of single sided 1 oz copper, in still air conditions; device measured when
operating in steady state condition.
6. Thermal resistance from junction to solder-point (on the exposed collector pad).
7. Refer to JEDEC specification JESD22-A114 and JESD22-A115.
