FCX619
A Product Line of
Diodes Incorporated
Electrical Characteristics
(@T A = +25°C, unless otherwise specified.)
Characteristic Symbol Min Typ. Max Unit Test Condition
Collector-Base Breakdown Voltage BV
CBO
50 190 — V I
C
= 100µA
Collector-Emitter Breakdown Voltage (Note 8) BV
CEO
50 65 — V I
C
= 10mA
Emitter-Base Breakdown Voltage BV EBO
7 8.3 — V I E = 100µA
Collector Cutoff Current I
CBO
— — 100 nA V
CB
= 40V
Emitter Cutoff Current I
EBO
— — 100 nA V
EB
= 5.6V
Emitter Cutoff Current I
CES
— — 100 nA V
CES
= 40V
DC current transfer Static ratio (Note 8) h
FE
200
300
200
100
—
400
450
400
200
30
— —
I
C
= 10mA, V
CE
= 2V
I
C
= 200mA, V
CE
= 2V
I
C
= 1A, V
CE
= 2V
I
C
= 2A, V
CE
= 2V
I
C
= 6A, V
CE
= 2V
Collector-Emitter Saturation Voltage (Note 8) V
CE(sat)
—
13
150
190
240
25
220
260
320
V
I C = 100mA, I B = 10mA
I
C
= 1A, I
B
= 10mA
I
C
= 2A, I
B
= 50mA
I
C
= 2.75A, I
B
= 100mA
Base-Emitter Saturation Voltage (Note 8) V
BE(sat)
— 0.97 1.1 V I
C
= 2.75A, I
B
= 100mA
Base-Emitter Turn-on Voltage (Note 8) V BE(on)
— 0.89 1.0 V I C = 2.75A, V CE = 2V
Transitional Frequency f
T
100 165 — MHz
I
C
= 50mA, V
CE
= 10V
f = 100MHz
Output capacitance C obo
— 12 20 pF V CB = 10V, f = 1MHz,
Turn-On Time t
(on)
— 170 — ns V
CC
=10V, I
C
=1A
I B1 = -I B2 = 10mA Turn-Off Time t
(off)
— 750 — ns
Note: 8. Measured under pulsed conditions. Pulse width ≤ 300μs. Duty cycle ≤ 2%.
