DXT790AP5
A Product Line of
Diodes Incorporated
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Value Unit
Collector-Base Voltage V
CBO
-50 V
Collector-Emitter Voltage V
CEO
-40 V
Emitter-Base Voltage V
EBO
-6 V
Continuous Collector Current I C
-3 A
Peak Pulse Current I
CM
-6 A
Base Current I
B
-0.5 A
Thermal Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Value Unit
Power Dissipation
(Note 5)
P
D
3.2
W (Note 6) 1.7
(Note 7) 0.74
Thermal Resistance, Junction to Ambient Air
(Note 5)
R θJA
39
°C/W (Note 6) 75
(Note 7) 169
Thermal Resistance, Junction to Lead (Note 8) R θJL 8.9 °C/W
Operating and Storage Temperature Range T
J
, T
STG
-55 to +150 °C
Notes: 5. For a device mounted with the exposed collector pad on 50mm x 50mm 2oz copper that is on a single-sided 1.6mm FR4 PCB; device is measured
under still air conditions whilst operating in a steady-state.
6. Same as note (5), except the device is mounted on 25mm x 25mm 1oz copper.
7. Same as note (5), except the device is mounted on minimum recommended pad (MRP) layout 1oz copper.
8. Thermal resistance from junction to solder-point (on the exposed collector pad).
