DJT4031N
Document number: DS31603 Rev. 2 - 2
4 of 5
March 2009
© Diodes Incorporated
DJT4031N
NEW PROD
UC
T
0.00001
0.0001
0.001
0.01
0.1
1
10
100
1,000
Fig. 8 Transient Thermal Response (Note 3)
t , PULSE DURATION TIME (s)
1
10,000
0.001
0.01
0.1
1
r(t)
,
T
R
ANSI
EN
T
T
H
E
R
MA
L
R
ES
IS
T
AN
C
E
T - T = P * R
(t)
Duty Cycle, D = t /t
J
A
JA
1 2
θ
R
(t) = r(t) *
θJA
R
R
= 101°C/W
θ
θ
JA
JA
P(pk)
t
1
t
2
D = 0.7
D = 0.3
D = 0.1
D = 0.05
D = 0.02
D = 0.01
D = 0.005
D = Single Pulse
D = 0.9
D = 0.5
Ordering Information
(Note 5)
Part Number
Case
Packaging
DJT4031N-13
SOT-223
2500/Tape & Reel
Notes:
5. For packaging details, go to our website at
Marking Information
Package Outline Dimensions
SOT-223
Dim Min Max Typ
A 1.55
1.65
1.60
A1 0.010
0.15 0.05
b1 2.90 3.10 3.00
b2 0.60 0.80 0.70
C 0.20
0.30
0.25
D 6.45
6.55
6.50
E 3.45
3.55
3.50
E1 6.90 7.10 7.00
e — —
4.60
e1 — — 2.30
L 0.85
1.05
0.95
Q 0.84
0.94
0.89
All Dimensions in mm
ZNS34 = Product Type Marking Code
YWW = Date Code Marking
Y = Last digit of year (ex: 8 = 2008)
WW = Week code 01 - 52
A1
A
ZNS34
YWW
