DSS20200L
Absolute Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Value Unit
Collector-Base Voltage V
CBO
-20 V
Collector-Emitter Voltage V
CEO
-20 V
Emitter-Base Voltage V
EBO
-7 V
Peak Pulse Collector Current I
CM
-4 A
Continuous Collector Current I
C
-2 A
Thermal Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Value Unit
Power Dissipation
(Note 5)
P
D
600
mW
(Note 6) 1.2
Thermal Resistance, Junction to Ambient Air
(Note 5)
R
θJA
209
°C/W (Note 6) 104
Thermal Resistance, Junction to Leads (Note 7) R
θJL
75
Operating and Storage Temperature Range T
J
, T
STG
-55 to +150 °C
ESD Ratings
(Note 8)
Characteristic Symbol Value Unit JEDEC Class
Electrostatic Discharge - Human Body Model ESD HBM 4,000 V 3A
Electrostatic Discharge - Machine Model ESD MM 400 V C
Notes: 5. For a device mounted on minimum recommended pad layout with 1oz copper that is on a single-sided 1.6mm FR4 PCB; device is measured under still
air conditions whilst operating in a steady-state.
6. Same as note (5), except mounted on 25mm x 25mm 1oz copper.
7. Thermal resistance from junction to solder-point (at the end of collector lead).
8. Refer to JEDEC specification JESD22-A114 and JESD22-A115.
