DDZ9689T - DDZ9717T
Document number: DS30553 Rev. 7 - 2
2 of 7
November 2013
© Diodes Incorporated
DDZ9689T - DDZ9717T
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic
Symbol
Value
Unit
Forward Voltage @ I
F
= 10mA
V
F
0.9
V
Thermal Characteristics
Characteristic
Symbol
Value
Unit
Power Dissipation (Note 6)
P
D
150
mW
Thermal Resistance, Junction to Ambient Air (Note 6)
R
θJA
833
°C/W
Operating and Storage Temperature Range
T
J,
T
STG
-65 to +150
°C
Notes:
6. Device mounted on FR-4 PC board with recommended pad layout, which can be found on our website at
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Type
Number
Type
Code
Zener Voltage Range (Note 7)
Maximum Reverse
Leakage Current (Note 8)
V
Z
@ I
ZT
I
ZT
I
R
@ V
R
Nom (V)
Min (V)
Max (V)
µA
µA
V
DDZ9689T
HH
5.1
4.85
5.36
50
5
3
DDZ9690T
HJ
5.6
5.32
5.88
50
2
4
DDZ9691T
HK
6.2
5.89
6.51
50
1
5
DDZ9692T
HL
6.8
6.46
7.14
50
0.1
5.1
DDZ9693T
HM
7.5
7.13
7.88
50
0.1
5.7
DDZ9694T
HN
8.2
7.79
8.61
50
0.1
6.2
DDZ9696T
HP
9.1
8.65
9.56
50
0.1
6.9
DDZ9697T
HQ
10
9.50
10.50
50
0.1
7.6
DDZ9698T
HR
11
10.45
11.55
50
0.05
8.4
DDZ9699T
HS
12
11.40
12.60
50
0.05
9.1
DDZ9700T
HT
13
12.35
13.65
50
0.05
9.8
DDZ9701T
HU
14
13.30
14.70
50
0.05
10.6
DDZ9702T
HV
15
14.25
15.75
50
0.05
11.4
DDZ9703T
HW
16
15.20
16.80
50
0.05
12.1
DDZ9705T
HY
18
17.10
18.90
50
0.05
13.6
DDZ9707T
MD
20
19.00
21.00
50
0.05
15.2
DDZ9708T
ME
22
20.90
23.10
50
0.05
16.7
DDZ9709T
MF
24
22.80
25.20
50
0.05
18.2
DDZ9711T
MH
27
25.65
28.35
50
0.05
20.4
DDZ9712T
MJ
28
26.60
29.40
50
0.05
21.2
DDZ9713T
MK
30
28.50
31.50
50
0.05
22.8
DDZ9714T
ML
33
31.35
34.65
50
0.05
25.0
DDZ9715T
MM
36
34.20
37.80
50
0.05
27.3
DDZ9716T
MN
39
37.05
40.95
50
0.05
29.6
DDZ9717T
MO
43
40.85
45.15
50
0.05
32.6
Notes:
7. Nominal Zener voltage is measured with the device junction in thermal equilibrium at T
T
= 30°C ±1°C.
8. Short duration pulse test used to minimize self-heating effect.
